EBS MultiComp Studio Edition
Analog Compressor Pedal

OUR PART #:  EBS-SE-MC

The EBS MultiComp Studio Edition is a true dual band compressor that is easy to dial in and features a choice of solid state, tube simulation and multi-band compression.
Learn More
Our Price: $199.99
Write the first review.
EBS MultiComp Studio Edition
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Related Products

The EBS MultiComp Studio Edition is a true dual band compressor that is easy to dial in and features a choice of solid state, tube simulation and multi-band compression. Easily set the level of the Comp/Limit with one knob, Gain with another, then choose the type of compression between Tubeism, Multi-Band (MB) and Normal. An Active/Passive switch on the side allows for even more unique customization.

EBS MultiComp Studio Edition Features:

  • Preserve the low range
  • Suitable for live and studio use
  • Dual Band Compressor
  • Tubeism, Multi Band and Normal modes
  • Controls for Compression and Gain
  • True Bypass Signal Relay Switching
  • Protected against over voltage up to 18V
  • Powered by 9 to 12V DC
  • EBS AD-9+ Power Supply (sold separately)

EBS MultiComp Studio Edition Specifications:

  • Nominal Input Level: - 10 or - 4 dBv
  • Input Impedance: 700 kohms
  • Bypass Bandwidth: +0 / -3 dB 20 - 20k Hz
  • Gain Range: 0 - 15 dB
  • Compressor
    • Ratio min / max 1:1 - 5:1
    • Threshold -25 - +6 dB adjustable inside
    • Attack Time (80%) <10 ms
    • Release Time (80%) typ. 100 ms
  • Dimensions (LxWxH): 2.8" x 4.5" x 1.4” (70 x 115 x 35 mm)
  • Weight: 0.88 lb. (400g)
  • Power Requirements: 9-12 V DC Regulated, 35 mA max*
