Neutrik NXP-RM-ANA
Xirium Pro Analog Line Receiver

OUR PART #:  NXPRMANA

The Neutrik NXP-RM-ANA is an RX Analog line output module. It has outputs for up to (2) channels of line level analog audio.
Learn More
Our Price: $390.00
List Price: $394.00
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Neutrik NXP-RM-ANA
Qty:
In Stock

Similar Products
The Neutrik NXP-RM-ANA is an RX Analog line output module. It has outputs for up to (2) channels of line level analog audio.

Whether the signal type is analog, digital (AES/EBU) or Dante, XIRIUM PRO offers modules to accept any of them. Signal types may also be converted from one type to another, simply by selecting the appropriate module. Need to transmit an analog signal and plug into a digital input? No problem. Select an analog input module for the transmitter, and the AES digital output module for the receiver. In fact, every receiver in a system can use a different output module, allowing for signal conversion to the type used by your device.

Neutrik NXP-RM-ANA Specifications:

  • General:
    • Radio frequency carrier range: IEEE 802.11a, UNII-1 band from 5200 MHz to 5250 MHz (channels 40-48) and UNII-3 band from 5725 MHz to 5825 MHz (channels 149-165), license-free
    • Data protocol: Proprietary (DiWA technology)
    • Transmit power: Conducted 26 dBm / 32 dBm (with 6 dBi antenna) / 35 dBm (with 9 dBi antenna), FCC compliant
    • Range: Up to 1000 m point to point (LOS), longer range depending on obstacles, reflexions, interferences, XROC mode
  • Audio Performance (Analog to Analog Per WirelessLink):
    • THD + Noise (TX Gain = min.): < 0.01 % @ 1 kHz, 4 dBu / < 0.05 % @ 20 Hz – 10 kHz, 4 dBu
    • Frequency response: +0.5 dB / -1.5 dB @ 20 Hz – 20 kHz ref. 1 kHz
    • Dynamic range: > 105 dB @ 1 kHz, A-weighted
    • Crosstalk: < -80 dB @ 20 kHz
    • Number of audio channels @ 24 mbps: 2
    • Number of audio channels @ 6 mbps: 1 (XROC mode)
    • Number of receivers: Unlimited number of RX clients
    • Converter resolution (ADC & DAC): 24 bit
    • Sampling rate: 48 kHz
    • Latency (Delay): 3.6 msec (analog to analog)
    • Transmission method: Compression-free, no reduction of converted data
    • Operating temperature: 32°F to +122°F (0°C to +50°C)
    • Storage temperature: -4° F to +176° F (-20 °C to +80 °C)
