Zoom Focus Control Kit for Fujinon 8-Pin Video Lenses


The Varizoom VZ-PG-F provides remote zoom control for Fujinon 8-pin video lenses and will clamp to any tripod handle, jib...
Learn More
Our Price: $1,218.10
List Price: $1,249.00
Write the first review.
Usually ships in 7-14 business days.
Need it sooner? Call us!

Related Products

The Varizoom VZ-PG-F provides remote zoom control for Fujinon 8-pin video lenses and will clamp to any tripod handle, jib, or support bar with a unique off-set articulated swivel clamp for adjusting the angle of operation. The pistol-grip design allows left- or right-handed operation. The PG-F features a dual-variable system for versatile, precise control of zoom speed. Set the maximum desired speed on the dial (located in a "trigger" position), then use the pressure-sensitive rocker to vary the speed from a crawl all the way up to the preset max. Alternatively, depress the rocker fully and roll the dial with your index finger to ramp the speed up.

Varizoom VZ-PG-F Features:

  • Combination of pressure-sensitive zoom rocker and speed dial provides precise dual-variable zoom control
  • Speed dial acts as a limiter for max speed or a 'ramping' device
  • Red record/pause button
  • Video return button plays back the last 5 seconds of recorded material and cues the tape up to the last recorded frame to ensure proper timecode sync
  • Rubber-foam grip with a 'pistol grip' curve for ergonomic comfort
  • Designed for use with left or right hand
  • Heavy-duty, quick-release aluminum swivel clamp for angular adjustment of handle position
  • Compact, heavy-duty black aluminum housing

Varizoom VZFCF Features:

  • Heavy-duty focus handle with articulated swivel clampfor angular position adjustment
  • High-precision gear box fits on most Fujinon lenses
  • 40" industrial drive cable accommodates any tripod configuration and provides smooth manual control
  • Handle and cable are also compatible with other VariZoom gear boxes - buy one complete FC-F focus control set, then just buy the VZ gear box for your other lens for savings

Varizoom VZM7K

This kit includes everything you need for monitoring your video productions. Starting with our ultra-sharp VZM7 monitor for accurate representation of your video feed, this kit includes accessories and features you won't find anywhere else. The collapsible sunhood/screen protector offers a professional look, excellent viewing outdoors, and superior protection during storage & transport. The high-capacity battery system will keep your monitor running for up to 6 hours. Pre-mounted with the kit are a Sony L series battery plate and the extremely handy HDMI locks to prevent the cable from loosening or damaging the monitor connectors should the cable get yanked or bent. Also included are the swivel shoe mount for attaching the monitor to your camera and the foam-lined hard case that holds everything together and protects your investment. Last but not least is the innovative zoom button that allows you to remotely put the monitor in pixel-to-pixel and peaking modes for extremely accurate focusing. Buy this kit to save or purchase the accessories a la carte. Don't forget about our optional VZM7-RC rubber case protector to make your monitor stand up to the rigors of field use.

Varizoom VZM7K Features:

  • VZM7 monitor with power supply and 2 HDMI cables (mini-std and std-std)
  • Hard Sunhood/Screen Protector
  • High Capacity L Series Battery 47Wh
  • Compact Travel Charger
  • Battery Plate Sony L Series (premounted)
  • Remote Zoom Button for Focus Assist
  • Swivel Shoe Mount for camera-top mounting
  • 2 HDMI locks for In and Out
  • Hard Case with foam lining
  • Accepts all HD signals up to 1080p
  • HDMI In / Out (loop through)
  • DSLR Scaling to allow full-screen viewing of image from cameras such as Canon 5D
  • Auto Aspect Ratio Detection
  • Monochrome (B&W) mode
  • Image Flip for inverted mounting
  • Safety Area markers (5 levels), Centerline Marker, 4:3 area markers
  • Underscan and Overscan modes
  • Color Temperature Presets (D65 and D93 standards), or user-defined through RGB settings
  • Brightness, Contrast, Saturation, Sharpness adjustments
  • Customizable Menu Options for menu duration, position, text color and language
  • Built-In Speaker and Headphone jack for audio monitoring
  • Pixel-to-Pixel Zoom and Peaking for Focus Assist

Varizoom VZ-PG-F Specifications:

  • Width: 2.4"
  • Length: 6.5"
  • Max Clamp Diameter: 1.25"
  • Cord Length: 40"
  • Weight: 1 lb
  • Material: Aluminum
  • Compatibility: Chart Located on Fujinon Broadcast Lens Controls Page
  • For: 8 pin Fujinon Lenses
  • Warranty: 2 years parts/labor

Varizoom VZFCF Features:

  • Handle Dimensions: 2.75" x 7.85"
  • Max Clamp Diameter: 1.25"
  • Drive Cable Length: 40"
  • Total Weight: 1.75 lbs
  • Construction: Aluminum, Stainless Steel, Brass
  • Compatibility: Compatible with Most Fujinon Lenses. Not compatible with A24x or A36x. For A12x6.8, S12x5, S14x7.3, S16x7.3 and Th16x5.5, see FC-F22)
  • Warranty: 2 years parts/labor

Varizoom VZMZK Features:

  • Includes:
    • Monitor
    • Power supply
    • 2 HDMI cables (standard-standard & standard-mini)
    • VZM7HD sunhood/screen protector
    • VZMBPS Sony L series battery plate
    • High-capacity battery (6hrs)
    • VZMCH charger
    • VZMZB remote zoom button
    • VZSHOE swivel shoe mount
    • VZMLOCK HDMI cable locks (2)
    • VZMCC hard carrying case.
  • Screen Size: 7" diagonal
  • HDCP Compliant: YES
  • Native Resolution: 1024 x 600
  • Brightness: 250 cd/m2
  • Contrast: 700:1
  • Backlight Type: LED
  • Video Formats:
    • 1080: 24p/24psf/25p/30p/50i/60i/50p/60p
    • 720: 50p/60p; 480i; 480p; 576i; 576p
  • Response Time: 10ms
  • Viewing Angle: L75° / R75° / U70° / D75°
  • Input Voltage: 12VDC nominal (6.5 – 36VDC max range)
  • Mount Type: 1/4"-20 female (4x – top, bottom, left, right)
  • Inputs/Outputs: HDMI (in), HDMI (out), Headphone 3.5mm (out), "Zoom" (in) 3.5mm, XLR power (4+, 1-)
  • Size: 8" x 5.4" x 1.5"
  • Weight: 1.25 lbs
  • Battery Capacity: 47 Wh / 6600 mAh / approx 6hrs runtime
  • Power consumption: </=8W
