EAW-Eastern Acoustic Wrks QX118
Dual 18" QX Series Subwoofer

OUR PART #:  QX118

The QX118 is the companion subwoofer for QX Series loudspeakers.
Learn More
Selected Model Price: $3,206.00
Be the first to review.

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

EAW-Eastern Acoustic Wrks QX118
Select model: (shipping times are approximate)
Qty:

Similar Products

The QX118 is the companion subwoofer for QX Series loudspeakers. Designed to extend the low frequency response of QX arrays to 30 Hz, this compact subwoofer features a high power 18” producing an exceptional amount of output. While the operating range is specified to 150 Hz when used with full-range QX products, the QX118 is capable of extended response to serve as an LF subsystem for MF/HF loudspeakers.

Six year warranty.

EAW QX118 Features:

  • QX Companion Sub
  • Installation Flexibility
  • Ideal for houses of worship, arenas, outdoor stadiums, performing arts venues, theaters and clubs

EAW QX118 Specifications:

CONFIGURATION

  • Subsystem:
    • Transducer: SUB 1x 18 in. cone
    • Loading: Vented
    • Amplifier Channels: Single-amp LF
    • External Signal Processing: DSP w/1-way filter

PERFORMANCE

  • Operating Range (-10 dB, Hz): 30 – 150
  • Axial Sensitivity (1W @ 1m, dB SPL):
    • Sub (whole space): 94
  • Power Handling/Impedance (Watts @ Ohms):
    • Sub (single amp): 800 @ 8
  • Calculated Maximum Output Peak (dB SPL):
    • Sub (whole space): 129
  • Calculated Maximum Output Long Term (dB SPL):
    • Sub (whole space): 123
  • Dimensions (inches/millimeters):
    • Height (front): 27.96/710
    • Height (rear): 15.87/403
    • Width (front): 27.96/710
    • Width (rear): 15.87/403
    • Depth: 23.82/605
  • Trap. Angle (degrees per side): 19.9
  • Trap. Angle (degrees top and bottom): 19.9
  • Weights (pounds/kilograms):
    • Net: 89/40.4
    • Shipping: 104/47.2
