DPA Microphones FIDB10-2
d:fine Dual-Ear Long-Boom Cardioid Headset Microphone Wired with Shure TA4F in Black

OUR PART #:  FIDB10-2

The DPA Microphones FIDB10-2 is a black, dual-ear, directional 4.3" long boom headset microphone with TA4 connections for Shure wireless bodypacks.
Learn More
Our Price: $819.95
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

DPA Microphones FIDB10-2
Qty:
In Stock

Similar Products

The DPA Microphones FIDB10-2 is a black, dual-ear, directional 4.3" long boom headset microphone with TA4 connections for Shure wireless bodypacks.

Staying true to the DPA legacy, d:fine offers accurate, natural voice intelligibility and very high SPL capabilities – users can both speak and sing into the mic with no hint of distortion.

DPA Microphones FIDB10-2 Features:

  • Pristine audio quality
  • Easy single-ear or dual-ear mounting
  • Minimal visual impact

DPA Microphones FIDB10-2 Specifications:

  • Directional characteristics:  Directional
  • Principle of operation:  Pressure or pressure gradient
  • Cartridge type:  Pre-polarized condenser
  • Frequency range:  20 Hz - 20 kHz
  • Frequency range, ± 2 dB:  Omni: 20 Hz - 20 kHz with 3 dB soft boost at 8 - 15 kHz. Directional: 100 Hz - 20 kHz with 3 dB soft boost at 8 - 20kHz.
  • Sensitivity, nominal, ± 3 dB at 1 kHz:  6 mV/Pa; -44 dB re. 1 V/Pa
  • Equivalent noise level, A-weighted:  Omni: Typ. 26 dB(A) re. 20 µPa(max. 28 dB(A)). Directional: Typ. 28 dB(A) re. 20 µPa (max. 30 dB(A)).
  • Equivalent noise level, ITU-R BS.468-4:  Omni: Typ. 38 dB (max. 40dB). Directional: Typ. 40 dB (max. 42 dB).
  • S/N ratio (A-weighted), re. 1 kHz at 1 Pa (94 dB SPL):  Omni: Typ. 68dB(A). Directional: Typ. 66 dB(A).
  • Total Harmonic Distortion (THD):  <1 % up to 123 dB SPL peak;<1 % up to 120 dB SPL RMS sine
  • Dynamic range:  Omni: Typ. 97 dB. Directional: Typ. 95 dB.
  • Max. SPL, peak before clipping:  144 dB
  • Output impedance:  From MicroDot: 30 - 40 ohm. From DAD6001-BC: 100 ohm.
  • Cable drive capability:  Up to 300 m (984 ft) with DAD6001-BC XLR adapter
  • Output balance principle:  Signal balanced with DAD6001-BC XLR adapter
  • Common Mode Rejection Ratio (CMRR):  > 60 dB from 50 Hz to 15 kHz with DAD6001-BC XLR adapter
  • Power supply (for full performance):  Min. 5 V to max. 50 V through DPA adapter for wireless systems. 48 V phantom power ± 4 V with DAD6001-BC XLR adapter.
  • Current consumption:  Typ. 1.5 mA (microphone). 3.5 mA with DAD6001-BC XLR adapter.
  • Connector:  Shure TA4F
  • Color:  Black
  • Weight:  Microphone boom: 0.8 g (0.03 oz); earhook: 1.1 g (0.04 oz); cable: 6.6 g (0.23 oz). Total: 8.5 g (0.30 oz).
  • Microphone head size (h x w x d):  0.37"(H) x 0.21"(W) x0.11"(D)
  • Capsule diameter:  5.4 mm (0.2 in)
  • Mic boom lengths:  4.3"
  • Cable length:  1.3 m (4.3 ft)
  • Cable color:  beige
  • Cable diameter:  1.6 mm (0.06 in)
  • Polarity:  +V at MicroDot pin for positive sound pressure (and pin 2 on DAD6001-BC XLR adapter)
  • Electro Magnetic Compatibility (EMC):  Fully compatible
  • Temperature range:  -40 °C to 45 °C (-40 °F to 113 °F)
  • Relative Humidity (RH):  Up to 90%

DPA Microphones FIDB10-2 Includes:

  • Make-up and moisture filter pre-mounted on the mic
  • Cable clip which anchors the cable to your clothing
  • Five color coded identification rings
  • Make-up cover/ capsule protection cap
  • Three windscreens
