Beyerdynamic STEGOS-TB
Wireless Condenser Boundary Microphone

OUR PART #:  STEGOS-TB

Wireless boundary mic for use with the STEGOS-RS receiver.
Learn More
Our Price: $712.53
List Price: $899.00
You save 21%!
Write the first review.
Beyerdynamic STEGOS-TB
Qty:
In Stock
Related Products

Wireless boundary mic for use with the STEGOS-RS receiver.

Features:

  • Semi-cardioid polar pattern
  • Illuminated multifunction button
  • Manual or Push-To-Mute operating mode
  • Power on LED / Charging LED
  • Operating time of max. 14 hours
  • DC connector for power supply operation and charging

Specifications:

  • Transducer type  Condenser (back electret)
  • Operating principle Pressure gradient
  • Polar pattern Semi-cardioid
  • Frequency response 20 Hz – 12 kHz
  • Dynamic range 68 dB (A-weighted)
  • Open circuit voltage 300 mV/Pa
  • Max. SPL at 1 kHz 100 dB SPL
  • RFI proof Scudio™ technology
  • Power consumption approx. 100 mA
  • Power supply 4.8 VDC via integrated NiMHrechargeable batteries (4 cells, each with 2100 mAh)
  • Operating time 14 hours at least; DC poweredpermanent operation possible with CA 2458 charging power supply unit
  • Charging time with power supply unit (15 VDC, 1.6A) max. 2 hours
  • Temperature range (at < 90% humidity) +10 °C– +40 °C (+50 °F – +104 °F)
  • Storage temperature (at < 90% humidity) -20°C – +55 °C (-4 °F – +133 °F)
  • Dimensions (L x W x H): approx 5.4" x 3" x 1.5")
  • Weight approx. 410 g (0.9 lbs)
