West Penn HA210-BY-FOOT
2-Conductor Jacketed Speaker Wire in Gray

OUR PART #  HA210-BY-FOOT

Our Price: $1.48
List Price: $1.95
Save up to 52% when you order by quantity!
Buy 50 @ $1.18 ea.
Buy 200 @ $1.06 ea.
Buy 400 @ $0.94 ea.
(Low Price Guarantee)
In Stock

10/2 Stranded bare copper conductors, jacketed - Cluster Speaker Cable.

CONSTRUCTION PARAMETERS

  • Conductor: 10AWG Bare Copper
  • Stranding: 65x28
  • Insulation Material: Polyolefin
  • Insulation Thickness: 0.012" Nom.
  • Number of Conductors: 2
  • Shield: None
  • Drain: None
  • Jacket Material: PVC
  • Jacket Thickness: 0.025" Nom.
  • Overall Cable Diameter: 0.275" Nom.
  • Approximate Cable Weight: 71lbs/1M' Nom.
  • Flame Rating: UL1685

ELECTRICAL & ENVIRONMENTAL PROPERTIES

  • Temperature Rating: -4 degrees F to 140 degrees F
  • Operating Voltage: 300VRMS
  • Max. Capacitance Between Conductors @ 1kHz: 32pf/ft nom.
  • DC Resistance per Conductor @ 68 degrees F: 1.10 Ohms/1M' Nom.
  • Insulation Colors: Black, White
  • Jacket Color: Gray
  • RoHS Compliant: Yes

MECHANICAL PROPERTIES

  • Max. Recommended Pull Tension: 220lbs
  • Min. Bend Radius (Install): 2.7"



West Penn HA210-BY-FOOT
2-Conductor Jacketed Speaker Wire in Gray

OUR PART #  HA210-BY-FOOT

Product Information:

10/2 Stranded bare copper conductors, jacketed - Cluster Speaker Cable.

CONSTRUCTION PARAMETERS

  • Conductor: 10AWG Bare Copper
  • Stranding: 65x28
  • Insulation Material: Polyolefin
  • Insulation Thickness: 0.012" Nom.
  • Number of Conductors: 2
  • Shield: None
  • Drain: None
  • Jacket Material: PVC
  • Jacket Thickness: 0.025" Nom.
  • Overall Cable Diameter: 0.275" Nom.
  • Approximate Cable Weight: 71lbs/1M' Nom.
  • Flame Rating: UL1685

ELECTRICAL & ENVIRONMENTAL PROPERTIES

  • Temperature Rating: -4 degrees F to 140 degrees F
  • Operating Voltage: 300VRMS
  • Max. Capacitance Between Conductors @ 1kHz: 32pf/ft nom.
  • DC Resistance per Conductor @ 68 degrees F: 1.10 Ohms/1M' Nom.
  • Insulation Colors: Black, White
  • Jacket Color: Gray
  • RoHS Compliant: Yes

MECHANICAL PROPERTIES

  • Max. Recommended Pull Tension: 220lbs
  • Min. Bend Radius (Install): 2.7"



Add to Cart

We're sorry, only of this item available



Call a Sales Pro at 800-356-5844 for more information
