Mogami W2930
2-Pair EZ/ID Bulk Multipair Snake Cable, Sold by the Foot

OUR PART #:  W2930-BLACK-BY-FOOT

Mogami's W2930 is a 2-pair EZ/ID Snake Cable.
Learn More
Our Price: $2.44
List Price: $3.33
Save up to 62% when you order by quantity!
  • Buy 50: $1.94 each.
  • Buy 100: $1.47 each.
  • Buy 150: $1.26 each.

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Mogami W2930
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

Mogami's W2930 is a 2-pair EZ/ID Snake Cable.

Mogami multicore cables
Designed for the highest level of audio performance and feature superb electrical and mechanical characteristics while remaining compact, superflexible, and easy to use.

Note: Priced & sold by the foot. Please call your Full Compass Sales Representative for more information or assistance in completing your by-the-foot cable order.

Mogami Multicore Cable Features:

  • 2-channel individually twisted shielded pairs.
  • XLPE (Cross Linked Polyethylene) insulation provides superb electrical characteristics and will not melt or shrink back during soldering.
  • Rugged and flexible construction that is easy to handle, even at temperatures down to -4° F (-20° C).
  • Easy cable identification system:
    • Channel numbers printed on each core jacket to ensure correct identification, regardless of which end is stripped.
    • Outer jackets of each pair are color-coded by standard resistor color code, allowing quick identification of conductor pairs.
    • Inner conductors are also color-coded based on the international standard resistor color code. Each pair is colour coded by jacket and conductor colour combination.
  • Each channel has a drain wire and served (spiral) bare copper shield. The drain wire simplify termination and can be crimped by the same size contact as the inner conductor pair.

Mogami Multicore Cable Specifications:

  • Number of Channels: 2
  • Ov. Dia. (Approx.): 0.295" (7.5mm)
  • Jacket Thickness (Approx. mm): 1.0(0.039")
  • Weight (kg/100m)(kg/328Ft): approx. 15.4 lbs (7 kg) per 328ft (100m)

Cable Core:

  • Conductor: 30/0.08A (0.15mm²) #26AWG (30×#40AWG)
  • Insulation: 1.0Ø XLPE (Cross Linked Polyethylene) (0.039")
  • Drain Wire: 7/0.18TA (0.18mm²) #25AWG (7×#33AWG)
  • Served Shield: Approx. 58/0.10A Served (spiral) Shield
  • Jacket (Covering): 2.8Ø Flexible PVC (0.110")
