Yorkville UCS1P
Powered Sub, 1500W, Carpeted


Our Price: $1,449.00
List Price: $1,999.00
You save 28%! (Low Price Guarantee)
Usually ships in 7-14 business days.
Need it sooner? Call us!

The UCS1P was designed for use with the any of the Unityâ„¢ passive or active loudspeaker systems - U15, U15P or U215 - and is the ideal active subwoofer to match their acoustic parameters. But as with all Yorkville subs, the UCS1P can be employed with any full-range enclosure, especially those with high output, in many cases without even the need of a crossover.

This 1,500-Watt "earth mover" takes full advantage of its horn-loaded design to deliver fierce bottom end from a surprisingly compact, single 15-inch, back-loaded subwoofer. The high level of performance UCS1P delivers, especially considering its manageable size, is the direct result of outstanding driver, enclosure and electronic design. Optimized horn flare geometry, careful attention to the front and rear internal chamber dimensions, as well as the use of a high performance long excursion 15-inch driver, gives the UCS1 surprisingly high output volume and deep, extended bass response. Added to that, the onboard electronics include a 1,500-Watt amplifier, full-time soft limiting, an active, adjustable low-pass filter (HF Rolloff) and an adjustable pre-EQ curve (Shape) for plug-and-play ease of use!

The UCS1P enclosure is constructed from solid 15mm 11-ply birch and features a heavy gauge perforated metal grill , integrated tilt-back wheels and four strategically placed bar handles to make moving and stacking the UCS1P as easy as it can possibly be for a subwoofer in this class. It comes in a black carpet covering to mate with the U15, U15P and U215, or is available in a black painted Ultrathane finish (UCS1B) for use with the Ultrathane painted versions of the Unityâ„¢ loudspeakers. (U15B and U215B).


  • System Type  Horn Loaded Subwoofer
  • Active or Passive  Active
  • Program Power (Watts)  1500 Watts (2400 Watts Peak)
  • Max SPL (dB)  139dB Peak (133dB Continuous)
  • Frequency Response (Hz +/- 3dB)  37 - 150
  • Crossover Frequency (Hz)  90 - 110
  • LF Driver(s)  15 inch, Ceramic Magnet, 3 inch voicecoil
  • LF Protection  Thermal / Overcurrent / Clip
  • LF Amplifier Type  3 tier class G
  • Cooling Scheme  Dual speed controlled fans
  • Power Consumption (typ/max)  792/960VA (8A @ 120V, 4A @ 230V)
  • Inputs  Line and Speaker
  • Inputs - 1/4 IN Jacks  Combi-jack
  • Inputs - XLR  1 line/speaker level Combi-Jack input
  • Input Impedance (Bal/UnBal)  Balanced
  • Input Sensitivity (Vrms Sine)  0.775
  • Level Controls  Volume
  • EQ Controls  Boost / Low Pass
  • Limiter  Peak / Average
  • LED Indicators  Clip / Limit
  • Other Controls / Features
    -Active Controls:
    -Master Level
    -BassBoost Level
    -HF Rolloff Frequency (80-150Hz)
    -Hi-Pass Output RolloffSwitch (90Hz, 100Hz, 110Hz)
    -Hi-Pass XLR Output
    -Speaker / Line levelinput switch
  • Corners  Metal
  • Feet  Rubber
  • Wheels  2 (Rear)
  • Bar Handles  2 (Side), 2 (Top), 1 (Bottom)
  • Pole Mount Adapter (1 3/8 IN -3.5cm)  1 (Top)
  • Enclosure Materials  15mm (5/8inch) 11-ply Russian Birch
  • Grille  Perforated Metal
  • Covering / Finish  Black Ozite (Carpet)
  • Dimensions (DWH xbackW COM inches)  27 x 22.25 x 41
  • Weight (lbs/kg)  155 / 70.3
