Community R.35-3896B
8" Ultra-Compact Horn-Loaded Triaxial Three-Way Loudspeaker in Black

OUR PART #:  R.35-3896B

From Community's R Sereis of loudspeakers, comes the R.35-3896B, which is a full-range 3-way loudspeaker graced with a 90° x 0° nominal beamwidth that comes in the color black.
Learn More
Our Price: $677.00
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Community R.35-3896B
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

From Community's R Sereis of loudspeakers, comes the R.35-3896B, which is a full-range 3-way loudspeaker graced with a 90° x 0° nominal beamwidth that comes in the color black. This unit is housed in the same size enclosure as the 10-inch R.35COAX, and is a triaxial 8-inch Carbon Ring Cone loudspeaker featuring Community’s exclusive MultiSource Waveguide™ technology which adeptly integrates the output from dual midrange compression drivers and a 1-inch exit HF compression driver into a single coherent source. Fully passive, it is voiced for flat musical reproduction without EQ and delivers class-leading SPL levels for a loudspeaker of its size.

NOTE: Actual product may vary in appearance and specification. For more information on this and other products, please contact your Sales Pro.

The R.35-3896 is a fully horn-loaded triaxial three-way, full-range loudspeaker system designed to provide high qualityvoice and music reproduction in applications requiring extreme weather resistance. It is designed to withstand long-term exposure to tough, environmental conditions and to provide musical performance normally only associated with indoor loudspeakers. The Music / Voice switch allows for additional application flexibility. The "Music" setting provides an out-of-the-box flat response and selecting "Voice"provides up to a 5dB boost for increased vocal projection and intelligibility. The LF cone is treated with the same NeverWet™ coating as the grille cloth to ensure trouble-free performance in the harshest conditions.

Community R.35-3896B Applications:

  • Theme and Amusement Parks
  • Swimming pools
  • Outdoor Entertainment Centers
  • Athletic Fields
  • Malls, Fairgrounds, Race Tracks
  • Convention Centers
  • Multipurpose Indoor/Outdoor
  • Cruise ShipsVenues
  • Factories
  • Stadiums and Arenas

Community R.35-3896B Features:

  • Excellent musicality and intelligibility, low distortion, and high sensitivity and output
  • Weather-resistant, compact, matte finish paintable high impact ABS plastic modified-trapezoidal enclosure
  • NeverWet™ treated grille and LF driver cones, polymerHF and MR diaphragms, and moisture-sealed crossover
  • Corrosion-resistant zinc-rich epoxydual-layer powder-coated (DLPC) steel grille and low-profile yoke
  • Innovative MultiSource Waveguide™ (MSW) horn design for high frequency and dual midrange drivers
  • 200W autoformer (standard)
  • LightGrey, Black and White finish standard. Custom colors available upon request
  • Five-year product warranty / Fifteen-yearenclosurewarranty

Community R.35-3896B Specifications (partial):

  • Operating Range: 80 Hz - 16 kHz
  • Sensitivity (1W/1m): 100 dB
  • Power Handling: 400W continuous @ 8 ohms
  • Continuous Max Output: 126 dB (132 dB Peak)
  • 70V/100V Autoformer: 200W, 100W, 50W, 25W (@70V only)
  • Nominal Beamwidth (H x V): 90° x 60°
  • Finish: Light Grey, Black or White ABS matte plastic, paintable with dual-layer powder-coated steel with NeverWet™ treated grille
  • Transducers: LF - 1 x 8" carbon ring cone; coaxial MF- 2x2.35” Multisource Waveguide™ compression drivers, and HF - 1 x 1" exit compression driver
  • Dimensions (H x W x D): 11.0" x 13.0" x 13.5" (279 x 330 x 343 mm)

NOTE: Additional specs and info can be found in the documentations tab above.
