Gantom Lighting DB22
DarkBox DMX LED Dimmer with FX

OUR PART #:  DB22

The Gantom DB22 DarkBox DMX is an ultra compact and scalable single output DMX tunable LED dimmer.
Learn More
Our Price: $66.50
List Price: $70.00
You save 5%!
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Gantom Lighting DB22
Qty:
In Stock

Similar Products

The Gantom DB22 DarkBox DMX is an ultra compact and scalable single output DMX tunable LED dimmer. The DarkBox DMX also has a variety of built-in patterns (blink, strobe, candle flicker, power surge flicker, and pulse) for special effects lighting without the need to program complex DMX signals. This device occupies 3 DMX channels, which controls brightness, speed, and mode, respectively.

The DarkBox DMX features a machined aluminum body to protect the unit in harsh environments as well as an upgraded MOSFET that allows for higher current capacity and protects against output short circuits.

Applications:

  • Dark attractions
  • Candelabras
  • Props and animatronics
  • Lanterns
  • Special effects strobe
  • Signage

Gantom DB22 DarkBox DMX Features:

  • Makes any dimmable 12V LED flicker, strobe, blink, surge, pulsate, or dim
  • Fully tunable speed and brightness for any mode
  • Standalone operation with DMX signal is possible if tuned and programmed with DMX Programmer iOS app, available free from theApple App Store
  • Previous setting is retained even when power is cut
  • LED indicator displays output mode even without external LEDs attached
  • Never repeating algorithm for unique and realistic flicker patterns
  • Can drive multiple fixtures in sync

Gantom DB22 DarkBox DMX Specifications:

  • Input:  12V
  • Power Rating:  Up to 1A load
  • Output:  12V PWM output, up to 1A load
  • Dimming:  PWM
  • Dimensions:  1.5" x 1.5" x 0.8" (38 x 38 x 19 mm)
  • Power connector:  2.1mm DC jack with screw terminal adapter
  • Signal connector:  3.5mm TRS jack with screw terminal adapter
  • IP Rating:  IP20

DMX Channel Descriptions

Ch 1:

  • Name:  Brightness Level
  • Level:  0-255
  • Description:  Dim to bright

Ch 2:

  • Name:  Speed
  • Level:  /
  • Description:
    • If Ch 3 is 0, Ch 2 controls blink speed
    • If Ch3 is non zero, Ch 2 controls speed of function

Ch3:

  • Name:  Built-In Functions
  • Descriptions:
    • Level:
      • 32-64:
        • Description:  Fade in
      • 65-96
        • Description:  Fade out
      • 97-127
        • Description:  Pulsing
      • 128-159
        • Description:  Surge
      • 160-191
        • Description:  Strobe
      • 191-255
        • Description:  Flicker
