EAW-Eastern Acoustic Wrks JF59
15" 2-Way 650 Watts at 8 Ohms Passive Trapezoidal Loudspeaker with 90°x45° Dispersion

OUR PART #:  JF59-BLACK

The EAW JF59 is part of newest additions to the celebrated JF Series of 2-way loudspeakers that redefine the concept of application flexibility.
Learn More
Our Price: $2,580.00
Write the first review.

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

EAW-Eastern Acoustic Wrks JF59
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The EAW JF59 is part of newest additions to the celebrated JF Series of 2-way loudspeakers that redefine the concept of application flexibility. The integration of premium neodymium components and legendary crossover design in an incredibly adaptable package offers unprecedented utility. All models natively offer a combination of portable features and M10 installation points.

Available universal accessories include trim plates that hide handles and provide a connection point for u-brackets, quick release flytrack segments that integrate into any enclosure and adjustable legs for use as a stage monitor. Add revolutionary EAW Focusing in the UX8800 Processor for the pinnacle of performance in any venue.

EAW JF59 Features:

  • Premium Performance
  • Application Flexibility
  • Neodymium Components
  • NT upgrade capability
  • Switch configurable powering modes

EAW JF59 Specifications:

  • Subsystem:  Transducer: LF 1x 15 in. cone; HF 1x 1.4 in. exit, 3 in. voice coil compression driver; Loading: LF - Vented, HF - Horn-Loaded
  • Operating Modes:
    • Amplifier Channels:  Single amp LF/HF; Bi-amp LF, HF
    • External Signal Processing:  High Pass Filter; DSP w/ EAW Focusing
    • Operating Range (-10 dB):  47 Hz - 20 kHz
  • Axial Sensitivity (1W @ 1m):
    • LF:  98 dB SPL
    • HF:  107 dB SPL
    • Full Range:  98 dB SPL
  • Power Handling/Impedance:
    • LF:  650 Watts @ 8 Ohms
    • HF:  200 Watts @ 8 Ohms
    • Full Range:  650 Watts @ 8 Ohms
  • Calculated Maximum Output Peak:
    • LF:  132 dB SPL
    • HF:  136 dB SPL
    • Full Range:  132 dB SPL
  • Calculated Maximum Output Long Term:
    • LF:  126 dB SPL
    • HF:  130 dB SPL
    • Full Range:  126 dB SPL
  • Nominal Coverage:  90°H x 45°V
  • Subsystems:
    • LF:  15" cone, vented
    • HF:  1.4" exit compression driver, horn-loaded
  • Powering:  Switchable, bi-amplified, passive
  • Dimensions:
    • Height:  25.20" (648mm)
    • Width (front):  18.32" (465mm)
    • Width (rear):  8.86" (225mm)
    • Depth:  17.13" (435mm)
  • Weight:  77 lbs (35.0 kg)
