Solid State Logic Alpha-Link MADI Live R
AD/DA Converter


Our Price: $4,429.00
(Low Price Guarantee)
Usually ships in 7-14 business days.
Need it sooner? Call us!

The Alpha-Link LIVE-R 2U 24 channel analog to digital and digital to analog converters with MADI & AES/EBU digital I/O. Unlike the standard Alpha Link MADI AX and SX The LIVE-R offers 96kHz converters with electronically balanced analogue in/out, fibre redundancy and dual power supplies. Remote control is possible via the SSL C-10 broadcast console on CAT-5 connector.\


  • 24ch 24bit 96kHz AD/DA Converters
  • Redundant MADI Fibre I/O connections
  • MADI I/O can be locked to the C10 HD and C100 HDS highly stable clocks
  • Selectable as a Clock Master device or can be externally synchronized to AES/EBU, Wordclock or video sync
  • 24 balanced Analogue I/O
  • 12 Pairs of AES Digital I/O
  • Fibre MADI guarantees pristine audio
  • Embedded control data simplifies cabling and operation
  • Analogue input/output metering via 24 tricolour LEDs
  • 56 or 64 Channel MADI modes
  • Supports Fs and 2Fs formats in either High Speed or Legacy modes
  • USB Interface for firmware updates
  • Compact 2U Rack enclosure
  • Redundant PSUs as standard
