Renkus-Heinz CFX42
Dual 4" + 1" HF 2-Way Stairstep Loudspeaker

OUR PART #:  CFX42

The Renkus-Heinz CFX42 loudspeaker puts the power of unique Renkus-Heinz developments to work for you.
Learn More
Selected Model Price: $489.00
List Price: $650.00
Save up to 25%!
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Renkus-Heinz CFX42
Select a Model: (shipping times are approximate)
Qty:

Similar Products

The Renkus-Heinz CFX42 loudspeaker puts the power of unique Renkus-Heinz developments to work for you.  Versatile enclosure designs, go-anywhere hardware and rugged construction help solve your sound reinforcement challenges easily and quickly.

Renkus-Heinz CFX42 Features:

  • Full-range 300 Hz to 20 kHz performance in a space saving 'in-wall" design.
  • High frequency diffraction slot provides smooth 150° by 60° coverage.
  • 1" Extended Range Titanium HF Driver - Provides smooth, low distortion high frequency performance to 20 kHz and beyond.
  • Dual Heavy-Duty 4" Woofers - Easily handle 240 Watts of program power.
  • Optional (sold separately)18 gauge metal backbox is "concrete pour" ready.
  • Built-in Crossover - Eliminates need for a separate electronic crossover and bi-amplification.

Renkus-Heinz CFX42 Specifications:

  • Sensitivity: 95 dB (1W/1m)
  • Maximum SPL: 122 dB peak
  • Dispersion: 150° H by 60° V
  • Frequency Response: 300 Hz to 20 kHz
  • HF Driver: 1" Titanium driver, model SDA105-8; 15 WRMS, 30 W program
  • LF Drivers: Dual 4", model SSL4-6; 4" Woofers; 60 WRMS, 120 W program each.
  • Enclosure: Hardwood with perforated metal grille
  • BackBox: 18 ga. CRS with black powder coat.
  • Power: 240 Watts program at 16 Ohms
  • Connectors: Screw terminals & looping 4-pin Neutrik Speakon style connectors
  • Dimensions:
    • Enclosure: 5-3/8" H x 16-5/8" W x 9-5/8" D (13.7 x 42.2 x 24.4 cm)
    • Grille: 5-3/4" H x 17" W x 1/4" D (14.6 x 43.2 x .64 cm)
    • Back Box: 5-5/8" H, x 16-7/8" W x 13-3/16" D (14.2 x 43 x 33.5 cm)
  • Net Weight: 16.8 lbs (7.7 kg)
