AJA Video Systems Inc 3GM
3G/1.5G HD-SDI Multiplexer

OUR PART #:  3GM

The 3GM is a versatile and economical tool for interconnecting dual-link 1.5G SMPTE372M and 3G SMPTE425M.
Learn More
Our Price: $795.00

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

AJA Video Systems Inc 3GM
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The 3GM is a versatile and economical tool for interconnecting dual-link 1.5G SMPTE372M and 3G SMPTE425M. 3GM is bi-directional - allowing dual 1.5G to 3G or 3G to dual 1.5G conversion. Additionally, 3GM's 3G HD-SDI output is configurable for SMPTE425M type A or B. The 3GM can even convert 3G from/to type A or B. 3GB also provides a monitor output which is a single link SMPTE292M 1.5G HD-SDI. The 3GM is also compatible with SMPTE259M 270Mb SDI.

AJA 3GM Features:

  • Compact 3B to/from 1.5G conversion
  • SMPTE425M-AB inputs, 3G outputs configurable to A o rB
  • Converts SMPTE425M A to/from SMPTE425M B
  • Provides SMPTE292 monitor output for dual 1.5G or 3G inputs
  • Fully equalizing and re-clocking with jitter attenuation
  • Passes all ancillary data
  • Required power supply is included

AJA 3GM Specifications:

  • Formats: 3Gb, 1.5Gb, 270Mb Auto Select
  • Video Inputs: 2 HD-SDI, SDI (SMPTE 259/292/296/424),2x BNC
  • Video Outputs: 3G HD-SDI, HD-SDI, SDI, 3x BNC
  • Power: +5VDC Regulated, 4 Watts, Requires Power Supply (INCLUDED)
  • Size: 4.6" x 2.4" x 1"
