Panasonic TH49SF2U TH-49SF2U

The Panasonic TH-49SF2U 49" LED display comes equipped with Digital Signage Functions. The SF2 Series uses a high-visibility IPS panel and a variety of functions that support signage use. It also features signage control functions like the USB Media Player, which lets you simply insert a recorded USB media device for automatic playback, and Content Management Software, which makes it easy to create playlists combining video and still images.

Panasonic TH-49SF2U Features:

• High brightness for displaying easy-to-see content in bright places
• Failover and failback safeguards for mission critical situations
• HDMI CEC device linking supported
• USB media player for simple signage use without an STB
• Multi monitoring & control software (free) lets you control devices in groups
• Make your signage easy with Panasonic application
• DIGITAL LINK function enables simple installation and low system costs
• Cloning function saves labor when setting up multiple devices
• USB memory network settings
• Timer-programmable switching of device connection
• Smooth switching of presenters
• Customizable original screen
• High reliability
• Choose the installation to match Your application

Panasonic TH-49SF2U Specifications:

• Display Panel:
  • Screen Size: 49" (1232 mm)
  • Panel Type/Backlight: IPS Panel/E-LED
  • Aspect Ratio: 16:9
  • Effective Display Area (W x H): 1073 x 604 mm (42.2" x 23.7")
  • Resolution (H x V): 1920 x 1080
  • Brightness (Typ): 450 cd/m²
  • Contrast Ratio: 1100:1
  • Response Time: 12 ms (G to G)
  • Viewing Angle (H/V)" 178°/ 178° (CR=10)
• Terminal:
  • VIDEO In/Audio In: 4-pole Mini-jack (M3) x 1 (Audio in: shared with DVI-D/PC In)
  • HDMI In: HDMI Type A Connector x 2
  • DVI-D In: DVI-D 24-pin x 1 (DVI Revision 1.0 compliant), HDCP 1.1 compatible
  • Audio In (L/R): Stereo Mini-jack (M3) x 1 (Shared with PC/VIDEO In)
  • PC In: Mini D-Sub 15-pin x1 (DDC2B compatible)
  • Audio In (L/R): Stereo Mini-jack (M3) x 1 (Shared with DVI-D/VIDEO In)
  • USB: USB TYPE A Connector x 1, DC 5V/1A (USB 3.0 is not supported)
  • Audio Out (L/R): Stereo Mini-jack (M3) x 1
  • Serial In/Out: D-Sub 9-pin (Male) x 1/ x 1, RS-232C Compatible
  • LAN:
    • RJ45 x 1, 100BASE-TX, compatible with PJLink™ for TH-65SF2E (for Europe/CIS) and TH-65/55/49/43SF2W (for Asia, Middle East, Africa) (Shared with DIGITAL LINK)
    • 10BASE-T/100BASE-TX, compatible with PJLink™ for TH-55/49/43SF2E (for Europe/CIS) and TH-65/55/49/43SF2U (for Americas)
  • DIGITAL LINK: RJ45 x 1, 100BASE-TX, compatible with PJLink™
  • IR In/Out: Stereo Mini-jack (M3) x 1/ x 1
• Built-in Speaker: 20 W [10 W + 10 W]
• Electrical:
  • Power Requirements: 110-240 V, AC, 50 Hz / 60 Hz
  • Power Consumption: 110 W
  • On Mode Average Power Consumption: 73 W
  • Power off Condition: Approx. 0.3 W
  • Stand-by Condition: Approx. 0.5 W
• Mechanical:
  • Dimensions (WxHxD): 1098 × 634 × 46 mm (43.2" x 24.9" x 1.8")
  • Weight: Approx. 14.7 kg (32.4 lbs)
  • Bezel Width: T/R/L: 9.5 mm (0.38"), B: 15.5 mm (0.61")
  • Carton Size (WxHxD): 1292 × 883 × 203 mm (50.9" x 34.8" x 8.0")
  • Gross Weight: Approx. 20.0 kg (44.1 lbs)
  • Cabinet Material/Color: Metal (front), resin (rear cover)/Black
  • Pitch for Wall-Hanging: VESA compliant 400 x 400 mm (15.8" x15.8")
• Installation Requirement:
  • Orientation: Landscape/Portrait (Angle adjustment 0° - 45° for both left and right with landscape setting. When installing the portrait setting, be sure that the Power Indicator comes to the upside.)
  • Tilting Angle:
    • Landscape setting: 0° - 45° forward/backward
    • Portrait setting: 0° - 45° forward/backward
  • Environment:
  • Operating Environment:
    • Temperature: 0°C to 40°C (32°F to 104°F)
    • Humidity: 20 % to 80 % (Non Condensation)
  • Operating Time: 24 h/day
