Product Overview
CueServers from Interactive Technologies are powerful lighting control and show playback processors designed to be completely self-contained and extremely cost effective. Available in a series of models, these powerhouse controllers provide limitless solutions to the lighting professional. The CueServer 2 Mini (CS-920) is the smallest of the CueServer 2 models and is housed in a rugged anodized aluminum enclosure suitable for desktop use or panel, DIN, or truss mounting using optional bracket kits.
The CueServer 2 Mini can output shows utilizing up to 16,384 channels and features two built-in modular DMX slots that are user-configurable with any of seven available port modules. These interchangeable modules allow CueServer 2 Mini to be customized for different installation environments eliminating the need for external adapters. CueServer 2 Mini also features two user-definable function buttons with RGB indicators, two contact closure inputs, two low-voltage digital outputs, a serial port, and stereo audio output. Available in a series of models, this powerhouse controller provides almost limitless solutions to the lighting professional.
NOTE: DMX male and female modules shown in the pictures are not included, they must be purchased separately.
Common applications for the CueServer 2 Mini include:
- Commercial or Residential
- Architectural or Entertainment Lighting
- Themed Entertainment Venues
- Cruise Ships
- Museums
- Broadcast Studios
- Water Fountains
- Trade Shows
- Building Management
Interactive Technologies CueServer 2 Mini Includes:
- CueServer 2 Mini with power supply
- Two empty DMX module slots
- Terminal block
- 512 channel license
Interactive Technologies CueServer 2 Mini Features:
- Completely self-contained lighting playback, architectural processor, and DMX fade engine
- Seamless handling of Cue Lists, Presets, and Streams
- Control of up to 32 universes of DMX or 32 independent playback timelines
- Dynamic patching of up to 16,384 channels to 128 separate sACN, Art-Net, or KiNET universes
- Flexible module-based bi-directional DMX ports for custom jack configurations
- Front-panel configurable function buttons with RGB indicator LEDs
- Creation of lighting scenes directly or capture from external sources
- Powerful CueScript scripting language
- Real-Time clock with astronomical and calendar events
- Built-in web server for hosting custom interactive web pages
- Multi-show storage on removable micro SD memory card
- System integration via Ethernet, Serial, Digital I/O, and Audio
- Compatible with CueStation buttons and CueTouch touchscreens
- Easy interfacing with Crestron, AMX, Vantage, Control4, Medialon, Savant and other automation systems
- Native programming environment for both Mac and Windows
- Small anodized aluminum enclosure with optional brackets
Interactive Technologies CueServer 2 Mini Specifications:
- Part Number: CS-920
- Installable Options:
- DMX Channels:
- 512 Channels
- Up to 16,384 Channels may be licensed
- Capacity (per Show):
- Universe Patching: 128 sACN, Art-Net, or KiNET universes
- Playbacks: Up to 32, depending on number of Channels **
- Cues: 1,000,000 per Cue Stack*
- Cue Stacks: Unlimited*
- Groups: 100,000*
- Macros: 100,000*
- Global Rules: 1,000*
- Timer Events: 1,000*
- External Button Stations: 1,000*
- Audio Clips: Unlimited*
- Web Content: Unlimited*
- Protocols:
- Ethernet: UDP, TCP, HTTP, TELNET, NTP, Streaming ACN (sACN), Art-Net, KiNet v1/v2, CueScript, CueStation
- Serial: User-Defined ASCII, CueScript, CueStation
- Connections:
- Power: 2.1mm DC Power Input Jack
- Network: RJ45 10/100 Base-T Ethernet
- DMX: (2x) Bi-directional DMX module slots for custom configuration of preferred jack type
- I/O: 8-Position Pluggable Terminal Block for 2 Contact Closure Inputs, 2 Low-Voltage Digital Outputs, RS-232 Serial Port and Auxiliary 5VDC Output (200mA Max)
- Audio: 3.5mm (1/8”) Audio Jack for stereo audio output
- USB:
- (1x) Type-A USB Host Port
- (1x) Micro-B USB Device Port
- User Interface:
- Function Buttons: (2x) User-Defined Function Buttons with RGBLEDs
- Power:
- Memory:
- Removable Card: Micro SD (FAT32 formatted cards up to 2TB)
- Real Time Clock:
- Type: Battery-backed, 1 second resolution, less than +/-5ppm drift
- Synchronization: Automatic using Network Time Protocol (NTP)
- Event Triggers: Time of day, day of week, day of month, week of month, year, date range, astronomical time (relative to sunrise or sunset +/- specified offset)
- Physical:
- Width:
- 4.27” (109 mm) without mounting brackets
- 4.81” (122 mm) with vertical mounting bracket
- 5.13” (130 mm) with vertical DIN mounting bracket
- 6.15” (156 mm) with horizontal mounting brackets
- Length: 3.43” (87 mm)
- Height: 1.77” (45 mm)
- Weight: 0.7 lbs. (0.32 kg)
- Environmental:
- Operating Temperature: -13° to 158° F (-25° to 70° C)
- Storage Temperature: -40° to 176° F (-40° to 80°C)
- Humidity: 5 to 95%, non-condensing
- Altitude: 10,000 feet maximum
NOTE:
This item requires output modules to send DMX, see the Accessories tab for options. For more information on this and other products, please contact your Sales Pro.
**NOTE: The number of channel universes times the number of playbacks must be 32 or less.
* NOTE: These parameters may be limited by available SD Card storage space.
