Teac TN-570
2 Speed Belt Driven Turntable

OUR PART #:  TN-570

TEAC's flagship turntable TN-570 is designed on the concept of combining high style plus performance excellence as an analog turntable...
Learn More
Our Price: $1,099.99
List Price: $1,299.00
You save 15%!
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Teac TN-570
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

TEAC's flagship turntable TN-570 is designed on the concept of combining high style plus performance excellence as an analog turntable, while providing Hi-Res digital audio quality. It delivers the highest standard of analog sound virtue to the audiophiles who have loved it for decades, as well as entry-level users who have just begun explore their audiophile interests.

Its cabinet features a combination of artificial marble with high-density MDF in a 2-layer sandwich structure (Dual-material Chassis). Along with assuring a high feedback margin, this design brings to realization a clear sound by abating the inherent resonant frequencies of different materials via the combining of them. Its power train uses a belt drive with TEAC designed automatic rotation adjustment mechanism (Platter Rotation Speed Servo System, or "PRS3"). Platter rotation speed changes are immediately detected by an optical sensor then used as feedback for the motor speed. This enables a high-precision rotation speed that can compete with heavyweight-class belt-drive and direct-drive systems, while still allowing a stylish and sleek cabinet design.

With its onboard MM-type Phono EQ Amplifier and A/D converter, its optical digital output delivers up to a 24-bit/192 kHz digital audio signal which is equivalent to Hi-Res Audio quality, while its USB port produces up to 16-bit/48 kHz to PC/Mac, in addition to a conventional Phono/Line analog audio output. By connecting these digital and analog outputs to a D/A Converter unit and Analog Amplifier, the TN-570 offers new hybrid ways to enjoy the listening of vinyl records with a choice of either analog or digital audio output.

Added possibilities include experiencing how the sound differs according to the connected D/A converter, and building a digital music archive through the recording of vinyl records on a computer.

TEAC TN-570 Features:

  • TN-570 Turntable
  • AC Adapter (GPE053A-120050-Z)
  • EP Adapter
  • Counter Weight
  • Head-shell
  • Cartridge (except. Canada model)
  • Acrylic Platter
  • Dust Cover
  • Hinges x 2,
  • Pulley Cover
  • Flat Belt
  • Washers x 4
  • Hex Wrench
  • RCA Audio Cable with GND terminals
  • Owner's Manual (including Warranty card)

TEAC TN-570 Features:

  • 45 and 33-1/3 rpm 2-speed Cogging-free Belt Drive Turntable
  • “PRS3” Platter Rotation Sensing Servo System for Precise Rotate Speed
  • Sleek Resonance-free Dual Material Compound by Marble Stone and High-density MDF
  • Crystal Clear Acrylic Platter with Perimeter Belt Drive
  • High-precision Spindle with Anti-static Carbon-coated base
  • Height Adjustable Anti-skating Tone-arm with PC-Triple C Wiring
  • Universal Head-shell with PC-Triple C Wiring
  • OPA1602 SoundPlus® Op-amp for Built-in Phono EQ Amplifier
  • MM Cartridge supplied from audio-technica
  • Built-in A/D Converter by Cirrus Logic and 24-bit/192kHz via Optical Digital Output
  • 16-bit/48kHz USB Digital Output
  • Honeycomb-shaped Bottom Case
  • Height Adjustable Feet
  • Machined Aluminum EP Adapter
  • Optional Reversible Static-free "WASHI" Turntable Sheet (SKU: TA-TS30UN-BW, sold separately)

TEAC TN-570 Specifications:

Turntable section

  • Type: Belt Drive
  • Motor: DC Motor
  • Speeds: 33-1/3 rpm, 45 rpm
  • Servo System: PRS3 (Platter Rotation Speed Servo System)
  • Rotation Detection Precision: less than ±0.05% (at 33-1/3 rpm)
  • Wow and Flutter: 0.1%
  • Signal-to-Noise Ratio: more than 67 dB (A-weighted, 20 kHz LPF)
  • Platter Material: Acrylic
  • Platter Size: Full-size (300mm diameter, 16mm thickness)
  • Platter Weight: approx. 3.1 lbs. (1.4 kg)

Tone-arm section

  • Type: Static Balanced S-shape Tone-arm (Height Adjustable)
  • Effective Arm Length: 223mm
  • Over-hang: 18mm
  • Tracking Error: less than 3°
  • Stylus Pressure Range: 0g to 5g
  • Supported Cartridge Weight: 15g to 23g(including Headshell)
  • Height Adjust Range: approx. 6mm
  • Anti-skating Adjustent: Supported

Cartridge section

  • Type: MM-type (equivalent to audio-technica AT100E)
  • Output Voltage: 4.5mV (1 kHz, 5cm/sec.)
  • Stylus Pressure: 1.4 g ±0.4 g
  • Cartridge Weight: 6.5 g ±0.2 g
  • Headshell Weight: 10 g (including Screw, Nuts, and Wires)

Phono EQ Amplifier section

  • Amplifier Type: MM-type (On/Thru switchable)

Analog Output

  • Connector: RCA Pin x 1 pair (gold-plated)
  • Output Voltage: Phono/Line switchable
  • Phono Output mode: 4.5mV (±3 dB)
  • Line Output mode: 230mV (–13 dBV)

Digital Outputs

  • USB Output:
    • Connector: USB B-type x 1 (DC 5V 500mA Bus-power supply required from PC)
    • Signal Format: PCM, 8k / 11.025k / 16k / 22.05k / 32k / 44.1k / 48kHz, 16-bit
  • Compatible OS:
    • Windows 7, 8, 8.1, 10
    • OS X:
      • Lion (10.7)
      • Mountain Lion (10.8)
      • Mavericks (10.9)
      • Yosemite (10.10)
      • El Capitan (10.11)
    • macOS Sierra (10.12)

Optical Output

  • Connector: TOS-link x 1
  • Signal Format: PCM (S/PDIF), 48k / 96k / 192kHz, 24-bit
  • Output Level: -21.0 to -15.0 dBm
  • Operation Power:
    • AC 100 to 240V 50/60 Hz
    • Consumption: 1.5 W (0.5 W at Standby)

Physical

  • Overall Dimensions (W x H x D, including protrusions): 16.9" x 5.2" x 14.0"  (430 x 131.5 x 355mm)
  • Weight: approx. 19.9 lbs. (9.0 kg)

Notes:
* RoHS complied?
* Design and specification may change without notice.
