Bogen Communications GS60 [RESTOCK ITEM]
60 Watt Mixer And Amplifier

OUR PART #:  GS60D-RST-02

NOTE: This is a RESTOCK item that has had its box opened or has been repackaged. It may have minor cosmetic flaws and may have been sold to a customer and returned.
Learn More
Sale Price: $386.25
List Price: $507.23
You save 24%!
Be the first to review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Bogen Communications GS60 [RESTOCK ITEM]
Qty:
In Stock

Similar Products

NOTE: This is a RESTOCK item that has had its box opened or has been repackaged. It may have minor cosmetic flaws and may have been sold to a customer and returned. Please contact your Sales Pro for more information on this and other products.

The Bogen Communications GS60 Gold Seal Series amplifiers are designed to meet the rigorous requirements of today's sophisticated sound systems. They combine unique and useable features with ultra high reliability and professional performance.

Designed with the sound contractor in mind, they provide unparalleled flexibility and versatility, without the need for add-on modules.

Bogen Communications GS60 Features:

  • (4) dedicated MIC inputs
  • (1) selectable MIC/TEL input
  • (1) selectable MIC/AUX input
  • (1) dedicated AUX input
  • 4-ohm direct coupled output
  • 8-ohm, 25V, 25VCT, and 70V transformer-coupled outputs
  • Rack mountable - 2RU package
  • Dual-function, 10-band graphic equalizer
  • True loudnes contour function
  • Audio Enhancement circuit for improved intelligibility
  • Switchable phantom power supply (15V DC)
  • Variable AUX input muting
  • Remote master volume control capability
  • Automatic level control
  • Input muting via contact on all inputs
  • Voice activated AUX muting on TEL input
  • AUX fade back after TEL page
  • Pre-amp Out/Power amp In (insert) connections
  • Booster amp output connection

Bogen Communications GS60 Specifications:

  • Power Rating (RMS): 60 watts
  • Frequency Response:
    • Transformer Output: 65 Hz to 20 kHz, +0/-2 dB @ -2 dB
    • Direct Output: 20 Hz to 20 kHz, +0/-1 dB @ rated power
  • Distortion:
    • Transformer Output: 0.5% (max.), 0.3% (typ.), 65 Hz to 20 kHz @ -2 dB
    • Direct Output: 0.5% (max.), 0.3% (typ.), 20 Hz to 20 kHz
    • Signal-to-Noise Ratio: Fundamental: -94 dB or better; AUX 1 & 2: -70 dB; Tel: -70 dB or better @ 600 ohms; MIC 1 through
    • MIC 6: -60 dB or better @ 200 ohms
  • Inputs/Outputs:
    • MIC: 6 Lo-Z balanced via 4 XLR connectors and 2 screw terminals; Sensitivity: 0.35 mV (200 ohms)
    • AUX: 2 Hi-Z RCA jacks; Sensitivity: 0.085V (10k ohms)
    • Telephone: Screw terminals; Sensitivity: 0.07V (600 ohms)
    • Output to Power Amp: 5V @ Rated Output via RCA jack
    • Power In/Pre Out: In 1V/Out 1V via RCA jacks
    • WMT1A Output: 25V @ Rated Output via RCA jack
    • Tape Output: 687 mV @ Rated Output via RCA jack
  • Output Impedance: All models: balanced or unbalanced8-ohms, 25V, 25VCT, 70V, 4-ohm direct
  • Output Regulation: Better than 2 dB from no load tofull load
  • AC Input Voltage: 120V AC
  • AC Current: 1.3 A
  • Thermal Emmissions (Full Power): 283.5 BTU/hr
  • Variable Mute Range: 0 dB to -30 dB (AUX 1 & 2)
  • ALC: Distrotion: less than 0.5%; Compression: 25 dB
  • VOX Threshold: Input 20 mV (vox control max. CW position)
  • Dimensions: 16.5" x 3.5" x 12"
  • Product Weight: 20 lbs
