Electro-Voice ELX200-15
15" 2-Way Passive Speaker

OUR PART #:  ELX200-15

The Electro-Voice ELX200-15 is a 15 inch, 2-way passive speaker.
Learn More
Our Price: $449.00
List Price: $785.75
You save 43%!
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Electro-Voice ELX200-15
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The Electro-Voice ELX200-15 is a 15 inch, 2-way passive speaker.

ELX200-15 features high-efficiency Class-D power amplifiers (up to 1200 W) with integrated QuickSmartDSP, and delivers up to 132 dB SPL utilizing transducers designed and engineered by EV (15-inch EVS-15M woofer coupled with a DH-1C 1-inch titanium compression driver).

ELX200 powered models are ideal for portable and installed applications, with lightweight and durable polypropylene enclosures, three M10 threaded mounting points and the proven ZLX handle design for easy lifting.

The QuickSmart Mobile wireless control and monitoring application, using Bluetooth® Low Energy (BTLE) technology, allows intuitive system control, configuration and monitoring of up to six powered ELX200 loudspeakers simultaneously. Receive alerts when your system is being overdriven, and control your system while in front of your speakers, not behind. Bluetooth® is available in select countries.

Electro-Voice ELX200-15 Specifications:

  • Available Color: Black
  • Connector Type: (1) Stereo RCA Input, (2) XLR/TRS combo jack, and (1) XLR
  • Coverage (Nominal -6 dB) H: 90°
  • Coverage (Nominal -6 dB) V: 60°
  • Crossover Frequency: 1600Hz
  • Depth: 15.12" (384mm)
  • Enclosure Material: Polypropylene Composite
  • Family: ELX200
  • Frequency Range (-10 dB): 48 Hz – 19 kHz
  • Frequency Response (-3 dB): 55 Hz – 16 kHz
  • Grill: 18 AWG steel with powdercoat
  • Height: 27.95" (710mm)
  • HF Transducer: DH-1C 1-inch titanium compression driver
  • LF Transducer: EVS-15M 381 mm (15 in)
  • Max. SPL/1m (calc): 132dB
  • Power Consumption: 100 - 240 V~, 50 - 60 Hz, 1.8A
  • Power Rating: 1200W
  • Powered or Passive: Passive
  • Shipping Weight: 48.06lbs (21.8kg)
  • Speaker Type: Full-Range
  • Suspension: (3) M10 suspension points
  • Weight Net: 41.67lbs (18.9kg)
  • Width: 16.65" (423mm)
  • Woofer Size: 15inch
Wall Mount Bracket for ELX200 2-Way Models
Electro-Voice ELX200-BRKT Wall Mount Bracket for ELX200 2-Way Models
The Electro-Voice ELX200-BRKT is a wall mount bracket for ELX200 2-way models.
179.00 313.25 43

Usually ships in 7-14 business days.
Need it sooner? Call us!
Free Shipping Available
Forged M10 Eyebolt kit set of 3 ELX200
Electro-Voice EBK1-M10-3PACK Forged M10 Eyebolt kit set of 3 ELX200
The Electro-Voice EBK1-M10-3PACK is a forged M10 3-pack short shank eye-bolt kit. Comes in silver.
98.83

Usually ships in 7-14 business days.
Need it sooner? Call us!
Free Shipping Available
