TechLogix Networx TL-INCT-01
In-line HDMI Controller & De-embedder

OUR PART #:  TL-INCT-01

The TechLogix Networx TL-INCT-01 is an in-line HDMI controller and de-embedder.
Learn More
Our Price: $249.99
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

TechLogix Networx TL-INCT-01
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The TechLogix Networx TL-INCT-01 is an in-line HDMI controller and de-embedder. The TL-INCT-01 eliminates the need for remote controls—simply place it in-line between the source and display. It senses activity on the HDMI stream and outputs control signals to connected devices. For example, connecting a tablet or laptop will automatically turn on the display. The TL-INCT-01 even has the smarts to turn on a projector and drop a screen.

TechLogix Networx TL-INCT-01 Features:

  • (1) HDMI input
  • (1) HDMI output
  • Senses HDMI activity & automatically outputs control signals to connected devices
  • Digital and analog audio de-embedding
  • Built-in CEC controller for display control
  • Built-in RS232 learning for display control
  • Built-in relay outputs for display control
  • 15 built-in EDID presets
  • 4K@60 compliant
  • HDCP 2.2 compliant
  • Built-in cable equalization & signal regeneration
  • Built-in ESD and surge protection

TechLogix Networx TL-INCT-01 Specifications:

  • Technical:
    • Input: 1 x HDMI IN
    • Input Signal Type: HDMI 2.0 with HDCP 2.2
    • Input Resolution Support:
      • VESA: 800x600@60Hz, 1024x768@60Hz, 1280x768@60Hz, 1280x800@60Hz, 1280x960@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1440x900@60Hz, 1600x900@60Hz, 1600x1200@60Hz, 1680x1050@60Hz, 1920x1200@60Hz
      •  SMPTE: 4096x2160@24/25/30/50/60Hz, 3840x2160@24/25/30/50/60Hz, 1080P@24/25/30/50/60Hz, 1080I@50/60Hz, 720P@50/60Hz, 576P@50Hz, 480P@60Hz
    • Input Video Level: 0.5-1.2 V p-p
    • Input DDC Signal: 5V p-p
    • Maximum Pixel Clock: 297MHz
    • Output: 1 x HDMI OUT
    • Output Signal Type: HDMI 2.0 up to 4K@60Hz(4:2:0 10-bit) and HDCP 2.2
    • Output Resolution Support:
      • VESA: 800x600@60Hz, 1024x768@60Hz, 1280x768@60Hz, 1280x800@60Hz, 1280x960@60Hz,  1280x1024@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1440x900@60Hz, 1600x900@60Hz, 1600x1200@60Hz, 1680x1050@60Hz, 1920x1200@60Hz
      • SMPTE: 4096x2160@24/25/30/50/60Hz, 3840x2160@24/25/30/50/60Hz, 1080P@24/25/30/50/60Hz, 1080I@50/60Hz, 720P@50/60Hz, 576P@50Hz, 480P@60Hz
    • Video Impedance: 100 O
  • General:
    • Operating Temperature: 32°F to 113°F (0°C to 45°C)
    • Storage Temperature: -4°F to 158°F (-20°C to 70°C)
    • Humidity: 10% to 90%, non-condensing
    • ESD Protection:
      • Human-body Model: ±8kV (Air-gap discharge)/±4kV (Contact discharge)
    • Surge Protection: Voltage: ±1 kV (Ten times respectively for the positive and negative voltage)
    • Electrical Fast Transient/Burst:
      • Data communication cord: 1 kV
      • Power cord : 2 kV
    • Power Supply: DC 12V 0.5A
    • Power Consumption (Maximum): =2 W
    • Device Dimensions (WxHxD): 4.72" x 0.79" x 3.15" (120 x 20 x 80mm)
    • Product Weight: 0.23kg
    • Certification: CE, FCC, RoHS
