Four Universe Design and Control Software


Now you can save time with a lighting design, documentation and visualization software that is both easy to learn and rewarding to use.
Learn More
Our Price: $1,295.00
Write the first review.
Usually ships in 7-14 business days.
Need it sooner? Call us!

Related Products

Now you can save time with a lighting design, documentation and visualization software that is both easy to learn and rewarding to use. With Elation's Capture NEXUMâ„¢ - a native Windows and Mac OS X application that lets you work with lighting, video, moving scenery, lasers and water jets. Capture NEXUMâ„¢ is available in 4 versions: Solo, Duet, Quartet, & Symphony.

This version, the Capture NEXUMâ„¢ Quartet supports a wide range of ethernet DMX protocols like Art-Net and sACN but also connects directly to High End and MA Lighting consoles as well as consoles that support CITP from brands such as ADB, Avolites, ChamSys and Strand Lighting. Capture NEXUMâ„¢ also plays back local video files, streams video directly from CITP/MSEX compatible and Green Hippo media servers, receives laser projector content from LaserAnimation Sollinger and Pangolin systems and live positioning information directly from Kinesys K2 systems.
Capture NEXUMâ„¢ is now a 64-bit application for both Mac OS X and Windows platforms. This allows Capture to use more RAM to accommodate the ever-growing production sizes, as well as the use of the latest computer technologies out there, such as SketchUp 2016 support on Mac OS X and moving to video playback and compression based on AVFoundation on Mac OS X and Windows Media Foundation on Windows.

New concepts, enhancements and features of Elation's Capture Nexum, including:

  • Accurate color visualization
  • Visualization performance and quality enhancements
  • Cinema 4D and Hantmade Stage import
  • DWG import enhancements, including material support
  • Data import enhancements, including a complete VectorWorks import workflow
  • High End Hog 4 patch export
  • NewTek NDI video streaming and video capture card support
  • DMX generated textures

Elation Capture Nexum Quartet Features:

  • Number of DMX Universes - 4
  • Record, Playback and Render Still Snapshots in High Resolution
  • Import Models via SKP, 3DS & OBJ Files with Layers, Groups and Materials
  • Full AtlaBase Library with On-Demand Addition of Missing Items
  • Laser feeds from LaserAnimation and Pangolin - 4
  • Video Playbacks from Local File - 4
  • Paperwork - Create Plots, Reports & Print
  • Video Streams from CITP/MSEX or Green Hippo Media Servers - 4
  • Import Models via DXF & DWG Files with Layers and Groups
  • Record, play back and render movie snapshots to video files
  • Create Stand-Alone Presentation Executables with Snapshots
  • Motion Controlled Cameras & Scenery using DMX and Kinesys K2
  • DMX Controlled Water Jet Effects - 4
  • Product Code: 1310000091

Computer System Requirements:

  • Mac OS X Users: Mac OS X 10.9 or later will be required.
  • Windows Users: 64-bit Windows 7 or later will be required. (If you are running a Windows 32-bit installation your Windows license covers you for 64 bits as well, but a full reinstallation of Windows is required.)

NOTE: Software cannot be returned.
