West Penn C207
99ft Segment of 12Ga 2C Cluster Speaker Cable

OUR PART #:  C207-SEG-99

NOTE: This is a 99ft Segment of C207 Cable The West Penn Wire C207 is a 12/2 Stranded bare copper conductors, unshielded and unjacketed - Cluster Speaker Cable.
Learn More
Sale Price: $47.18
List Price: $135.63
You save 65%!
Write the first review.

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

West Penn C207
Qty:
Similar Products

NOTE: This is a 99ft Segment of C207 Cable

The West Penn Wire C207 is a 12/2 Stranded bare copper conductors, unshielded and unjacketed - Cluster Speaker Cable.

West Penn Wire C207 Specifications:

  • Construction Parameters:
    • Conductor: 12AWG Bare Copper
    • Stranding: 65x30
    • Insulation Material: PVC/Nylon
    • Insulation Thickness: 0.015" PVC Nom. // 0.005" Nylon Nom.
    • Number of Conductors: 2
    • Shield: None
    • Drain: None
    • Jacket Material: None
    • Jacket Thickness: None
    • Overall Cable Diameter: 0.260" Nom.
    • Approximate Cable Weight: 52lbs/1M' Nom.
    • Flame Rating: UL1685
  • Electrical & Environmental Properties:
    • Temperature Rating: -4°F to 140°F
    • Operating Voltage: 300VRMS
    • Max. Capacitance Between Conductors @ 1kHz: 36pf/ft Nom.
    • DC Resistance per Conductor @ 68 degrees F
    • Insulation Colors: Black, Red
    • Jacket Color: None
    • RoHS Compliant: NO
  • Mehanical Properties:
    • Max. Recommended Pull Tension: 146 lbs
    • Min. Bend Radius (Install): 2.6"
