Pathway Connectivity 6201 Pathport C-Series Gateway with 2 DMX 5-pin XLRM Inputs

The orignal and most popular Pathport™ node, the Pathport C-Series, is suitable for flush mount, permanent installation or for portable use. The 6201 model, is a Pathport C-Series node with a pair of 5-pin XLR male DMX inputs.

Pathway C-Series 6201 Includes:

• Instructions/Operations manual
• Mounting ring for standard 2-gang backbox

Pathway C-Series 6201 Features:

• Two DMX512 ports, individually configurable
• DMX routing on a universe or channel-by-channel basis
• Multiple source merging or prioritizing
• DMX output speed and signal loss behavior user-set
• LCD display provides status feedback
• Power-over-Ethernet (PoE) or auxiliary 24VDC power supply (by others)
• E1.20 RDM compliant as proxy device
• Manage up to 128 RDM responders per port
• Fits standard 2-gang, deep backbox
• Surface mount or portable enclosures as accessories
• Elegant design suitable for any location
• Supports the following Ethernet protocols:
  • E1.31 Streaming ACN (sACN)
  • Strand Shownet
  • Pathport Protocol
  • Art-Net
  • ETC Net2 (receive only)

Pathway C-Series 6201 Specifications:

• Power-over-Ethernet Class 1 device - 4W maximum
• Operating Conditions: 14 to 122°F (-10 to +50°C), 5-95% relative humidity, non-condensing
• Compliance:
  • USITT DMX512 –1990 ANSI E1.11 DMX512-A R2013
  • E1.20 RDM - Remote Device Management
  • E1.31 sACN - streaming ACN
  • IEEE 802.3af Power over Ethernet
  • ETL
  • CE
  • RoHS 2002/95/EC
• Physical:
  • 1 lb (0.45 kg)
  • 4.5”w x 4.7”h x 2.75”d ( 115mm x 120mm x 70mm)
