Pathway Connectivity 6705 VIA 5 DIN-Mountable Gigabit Ethernet Switch, No Fiber Connector

Pathway Connectivity's Pathport VIA 5 is a gigabit Ethernet switch designed specifically for lighting, sound and video signal routing in permanent installation applications. This model, the 6705 comes without an LC Fiber connector (this feature is optional and available with the 6706 model.)

The Pathport VIA 5 is easily mounted on 35mm DIN, with management features, such as VLANs, DHCP and IGMP multicast filtering, which are configured with VIA Manager software tools. Unlike switches designed and marketed for office and communication applications, VIA 5 ships pre-configured and optimized for entertainment network use, with 5 RJ45 copper ports and one optional connector for LC Multimode fiber. When needed, VLANs and other Layer 2/3 management features are easily accessed and configured through the Pathscape software suite.

Pathway 6705 VIA 5 Includes:

• DIN tray (housing) with end caps
• Installation/Operations manual
• 12" (250mm) piece of 35mm DIN rail

Pathway 6705 VIA 5 Features:

• Trap Art-Net and convert it to sACN
• IGMP querier and snooping, DHCP per VLAN
• Dante-compliant QoS option
• Link Layer Discovery Protocol (LLDP)
• Five RJ45 ports supporting 10/100/1000Base-T speeds
• One optional multi-mode LC fiber optic port
• 24 or 48VDC Power Input
• Mounts to 35mm DIN Rail
• Hardware supports PoE (requires 48VDC power supply)

Pathway 6705 VIA 5 Specifications:

• 24 or 48VDC power input
• Operating conditions: 14 to 122°F (-10 to +50°C), 10-90% relative humidity, non-condensing
• 1.5A power consumption
• Compliance:
  • IEEE 802.1AB Link Layer Discovery Protocol
  • IEEE 802.3af—Power over Ethernet
  • RoHS 2002/95/EC
• Physical:
  • 0.70 lbs (.316kg)
  • 3.6” x 8.0” x 1.5” (91mm 200mm x 38mm)

NOTE:

Actual product may vary in appearance and specification. For more information on this and other products, please contact your Sales Pro.
