RCF WS-620XT
4 Ohm/70V 6" Coax, IP55 Marine-Grade Ceiling Speaker

OUR PART #:  WS-620XT

A ceiling speaker that can be flush-mounted in false ceiling or panels, the WS620XT from RCF has also been designed for external use, even on boats.
Learn More
Our Price: $66.00
List Price: $99.00
You save 33%!

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

RCF WS-620XT
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

A ceiling speaker that can be flush-mounted in false ceiling or panels, the WS620XT from RCF has also been designed for external use, even on boats. It employs a 160mm (6") loudspeaker, with a 25mm (1") coaxial tweeter. It's equipped with a line transformer that enables direct connection to constant voltage systems at 70 V or 100 V, plus it's possible to use the low impedance taps (4 ohm) removing the transformer. In this situation, the installation can be done even with reduced depth.

Applications:

  • High intelligibility Speech and Background music
  • Schools
  • Shopping malls
  • Hospital
  • Museums
  • Hotels
  • Office building

RCF WS-620XT Main Features:

  • Woofer 6" wide-band
  • 1" coaxial tweeter
  • 12 / 24 Watt (RMS/Music Power)
  • 70 Hz ~ 20 kHz
  • 105 dB (1 m / POWER MAX) max. SPL
  • Includes 100V transformer multitap
  • Easy to install
  • Simple power settings

RCF WS-620XT Specifications:

  • Loudspeaker: 6" woofer with coaxial 1" tweeter
  • Power (on 8-ohm load): 12 / 24 W (RMS / Music power)
  • Power: 12 W - 6 W - 3 W (100V)
  • Sensivity: 91 dB (1 W / 1 m)
  • Mx. SPL (6 W / 1 m)L: 105 dB(A) (1 m / POWER MAX)
  • Frequency Response: 70 Hz – 20 kHz
  • Angle of coverage: 150° / 100° / 70° @ 1 / 2 / 4 kHz (hor.)
  • Connector: 6-pin terminal strip
  • Body color: White RAL 9016
  • Main body material: Plastic
  • Grill material: Plastic
  • Dimensions: (Ø x H, with transformer): 6.49" x 4.52" (165 x 115mm)
  • Flush-mounting hole (Ø): approx. 5.2" (132mm)
  • Min ceiling thickness: approx. 0.2" (5mm)
  • Net weight: approx. 2.43 lbs (1.1 kg)
  • Relative humidity: 90% non-condensing
