ETC/Elec Theatre Controls N34G-DIN
Response Four-Port DIN-Rail Mount Gateway

OUR PART #:  N34G-DIN

The ETC N34G-DIN Four-Port Gateway is a DMX and RDM distribution device built on the quality and reliability of ETC's network development.
Learn More
Our Price: $995.00

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

ETC/Elec Theatre Controls N34G-DIN
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The ETC N34G-DIN Four-Port Gateway is a DMX and RDM distribution device built on the quality and reliability of ETC's network development. Built for networking systems using industry standard streaming ACN™ (sACN) protocol, the Four-Port Gateway is compatible with ETC network system products. It uses bidirectional Ethernet communication with other network devices to send or receive DMX512 data and RDM messages. The Four-Port Gateway supports up to four DMX inputs and outputs, Terminal Strip and RJ45 connections in any combination to transport up to 2048 channels of DMX over Ethernet.

The DMX/RDM Four-Port Gateway is a DIN-rail-mounted device with four ports with each port independently defined as an output or an input.

ETC N34G-DIN Features:

  • Supports Net3 using ACN and streaming ACN protocols
  • Supports up to four DMX wiring connections
  • Distributes up to 2048 Channels over Ethernet
  • Ports configurable for input or output
  • Supports Remote Device Management (RDM)
  • Supports Power over Ethernet (PoE 802.3af) or external power supply
  • Integrated LCD displays status and configuration information
  • Standard compact design supports tabletop, DIN-rail, rack-mount or touring configurations
  • Configured using Net3 Concert configuration software
  • ANSI E1.17 ACN protocol compatible
