JBL Control 24CT [B-STOCK MODEL]
4" 2-Way Ceiling Speaker with 70V/100V Transformer in White

OUR PART #:  CONTROL-24CT-BSTOCK

The JBL Control 24CT is a background / forground ceiling loudspeaker.
Learn More
Our Price: $29.66
List Price: $145.95
You save 80%!
Be the first to review.

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

JBL Control 24CT [B-STOCK MODEL]
Qty:
Similar Products

The JBL Control 24CT is a background / forground ceiling loudspeaker. The Control 24CT contains a coaxially mounted 4" woofer and 3/4" titanium-coated tweeter, providing high-fidelity sound over an extremely wide coverage area. The Control 24CT includes a multitap transformer for 70V or 100V systems.

JBL Control 24CT Features:

  • Coaxially mounted 100 mm (4 in) woofer with butyl rubber surround and 19mm (.75 in) titanium coated
  • High power, wide frequency response and low distortion for high soundlevel capability.
  • Wide coverage allows for fewer speakers
  • Packaged with grille, back can and tile rails for fast installation andeasy dealer stocking.

JBL Control 24CT Specifications:

  • Frequency Range: 80 Hz - 20 kHz
  • Power Capacity: 80 W Continuous Program Power; 40 W Continuous Pink Noise
  • Transformer Taps:
    • 70 V: 30 W, 15 W, 7.5 W and 3.7 W taps
    • 100 V: 30 W, 15 W, and 7.5 W taps
  • Nominal Coverage Angle: 130┬░ conical coverage
  • Directivity Factor (Q): 2.4 dB averaged 500 Hz to 4kHz
  • Directivity Index (DI): 3.8 dB averaged 500 Hz to 4kHz
  • Rated Maximum SPL: 102 dB @ 1 m (3.3 ft)
  • Nominal Impedance: 16 ohms (Min Z 16.1 ohms @ 320 Hz)
