Philmore B7015 15A Push Button Thermal Circuit Breaker

OUR PART #: B7015 MFR #: B7015

Copied to clipboard

Philmore's B7000 Series single pole thermal circuit breakers feature a recessed reset button which cannot be manually pulled out to disconnect the circuit. ...Read more

Philmore B7015 15A Push Button Thermal Circuit Breaker Image 1
Philmore B7015 15A Push Button Thermal Circuit Breaker
Sale Price: $0.99
List Price: $4.81
You save 79%!
Synchrony Music & Sound Card
No Interest if paid in full within 6 Months
Learn How
Item usually available to ship in 9-12 Business Days. Please call for up-to-date information on product availability.
For Parts Assistance, call 800-356-5844 and press "2" or email [email protected].

Product Overview

Philmore's B7000 Series single pole thermal circuit breakers feature a recessed reset button which cannot be manually pulled out to disconnect the circuit. When an overload occurs and the breaker opens, it allows the reset button to "pop out" for visible trip indication.

Philmore B7015 Push Button Thermal Circuit Breaker Specifications:

  • Amps: 15
  • Maximum Resistance: 0.010 Ohms
  • Trip Time @ 200% of Rating: 6 to 30 seconds
  • Input Power: 125 VAC / 250 VAC / 50 VDC
  • Dielectric Strength: 1500 VAC / 1 minute
  • Interrupt Capacity:
    • 125 VAC x 1000A
    • 250 VAC x 2000A
  • Insulation Resistance: > 100 M
  • Calibration:
    • 25 C - 100% of rated current - continously carried
    • 25 C - between 101% and 145% - may trip or not
    • 25 C - 150% of rated current - trip within 1 hour
    • 25 C - 200% of rated current - trip within 1 minute
  • Contact Endurance: 125 VAC x 150% of rated current - 500 cycles
