OCEAN MATRIX OMX-HDMI-2-IP-R [RESTOCK ITEM]
HDMI Over IP Extender/Receiver

OUR PART #:  OMX-HDMI-2-IP-RST-03

NOTE: This is a RESTOCK item that has had its box opened or has been repackaged. It may have minor cosmetic flaws and may have been sold to a customer and returned.
Learn More
Sale Price: $76.20
List Price: $99.95
You save 24%!
OCEAN MATRIX OMX-HDMI-2-IP-R [RESTOCK ITEM]
Qty:
In Stock
Similar Products

NOTE: This is a RESTOCK item that has had its box opened or has been repackaged. It may have minor cosmetic flaws and may have been sold to a customer and returned. Please contact your Sales Pro for more information on this and other products.

The Ocean Matrix OMX-HDMI-2-IP HDMI-R Over IP Converter/Extender Receiver is half of a system that lets you stream HDMI over your entire network. No longer is distance a limitation when sending HDMI. Converts HDMI to standard TCP/IP and transmits the signal over your local area network.

The advantage of converting HDMI to TCP/IP is that you can send HDMI over your entire network, freeing you of the typical limitations found in send/receive point-to-point systems. The Ocean Matrix OMX-HDMI-2-IP-R is great for use in PRO-AV projection networks, digital signage systems and educational streaming applications.

Ocean Matrix OMX-HDMI-2-IP-R Features:

  • Multiple transmitters and multiple receivers (up to 8 per transmitter -not included) can be paired on the same network.
  • May Also be Used as a Standard Point-to-Point (up to 120 meters) Transmit & Receive for On-Location Monitoring & Content Delivery
  • Robust Aluminum Housing

Ocean Matrix OMX-HDMI-2-IP-R Specifications:

  • HDCP Support: HDCP1.2
  • Input HDMI resolution: 480i@60Hz; 480p@60Hz; 576i@50Hz; 576p@50Hz; 720p@50/60Hz; 1080i@50/60Hz; 1080p@50/60Hz;
  • Output HDMI resolution: 480p@60Hz; 576p@50Hz;  720p@50/60Hz; 1080p@50/60Hz
  • Supported Video Color Formats: 24 Bit/Deep color; 30 Bit/Deep color; 36 Bit Deep Color
  • Support audio format: DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
  • Max transmission rate: 10.2Gbps
  • Audio signal transmission format: L/R stereo audio
  • TMDS signal: 0.5-1.5Vp-p (TMDS)
  • DDC signal: 5Vp-p(TTL)
  • Input cable length: 5m (AWG26 HDMI1.3 standard cable)
  • Output cable length: 5m (AWG26 HDMI1.3 standard cable)
  • Transmission medium
  • Connector Type: RJ45
  • Twisted Pair Interface: Cat5e/6
  • Transmission distance: Cat6 up to 120m (Cat5e up to 100m)
  • Cabling standards: TIA/EIA568 B
  • Power Supply Voltage range: DC5V
  • Power comsumption: <3.6W
  • Dimensions (LxWxH): 4.25" x 2.25" x 1"
  • Weight: 0.3 lb
