Product Overview
Optoma's ZW300UST comes with state-of-the-art laser phosphor display technology to offer the best possible picture quality and overall enhanced color performance to bring unsurpassed imagery to spaces both large and small. With the ability to create rich colors and deep levels of black that a traditional lamp-based projector isn't able to produce, this projector's solid-state laser light source is able to provide over 20,000 hours of virtually maintenance-free operation. It's perfect for nearly any environment, including those with less space, such as classrooms, meeting rooms, boardrooms, and any digital signage applications.
With a throw ratio of .27, the WXGA ZW300UST can display a large 115" image from only 19" away, making it ideal for use in space-constrained environments including small classrooms, meeting rooms, boardrooms and digital signage applications. Allowing for presentations to transition from external sources seamlessly, the ZW300UST’s PC Free USB Media Player supports playback of video and audio files along with images and presentations shared directly from any USB device.
Featuring a powerful 10-watt speaker, the ZW300UST enhances presentations, videos and audio files by delivering crisp, robust audio. In addition, streaming and presenting is made easy with an MHL-powered HDMI port that supports popular dongles including Optoma’s HDCast Pro and Amazon’s FireTV. The USB port can also be used to power Optoma’s WHD200 Wireless HDMI system or Google’s Chromecast media dongle.
Includes
- AC power cord
- VGA to VGA cable
- Remote control
- Batteries for remote
- Multilingual CD-ROM user’s manual
- Quick start card
- Warranty card
Features
- 3200 lumens and 22,000:1 Contrast Ratio produce bright, striking imagery along with razor sharp text
- PC Free USB Media Player supports playback of video and audio files along with shared images and presentations
- Extensive I/O Connectivity with Dual HDMI featuring MHL, VGA-In, RJ-45, 2x Audio-In and USB Power
- Laser Phosphor Light Source provides 20,000+ hours of light source expectancy
- Powerful 10-Watt speakers enhance presentations and fill every room with crisp audio
- HDMI MHL port supports popular HDMI dongles including Optoma’s HDCast Pro,Chromecast, FireTV & more
Specifications
- Technical
- Aspect Ratio: 16:10
- Audio: 10W Speaker
- Brightness: 3,200 Lumens
- Compatible Aspect Ratio: 16:10 Native, 16:9 and 4:3 Compatible
- Connections
- (2) HDMI (with MHL)
- (1) Composite
- (2) Audio-In (3.5mm and RCA)
- (1) Mic-In 3.5mm
- (1) VGA-In
- (1) VGA-Out
- (1) Audio-Out 3.5mm
- RS232C
- RJ-45
- USB-A Power and PC-Free USB Media Player
- USB-B (Service)
- Contrast Ratio: 100,000:1 (Dynamic Black Enabled) / 22,000:1
- Control Unit: RS232, RJ45
- Display Technology: Single Texas Instrument DMD, 12 Degree 0.65" DMD X1, Type S600, DC3
- Displayable Colors: 1.07 Billion
- Keystone Corrections: ±40° Vertical
- Light Source Type: Laser Phosphor
- Light Source Life: Up to 30,000 Hours
- Lens Shift: None
- Maximum Resolution: WUXGA (1920 x 1200)
- Native Resolution: WXGA (1280 x 800)
- Noise Level 32 dB
- Offset: 120% (3% Variance)
- On-Screen Display: Complete On-Screen Menu Adjustments in 18 Languages
- Operating Temperature: Sea Level to 10,000 feet (@73°F); must manually switch to high-altitude mode at 5,000 feet and above
- Power Consumption: 335W (Bright), 225W (Eco)
- Power Supply: AC Input 100-240V, 50-60 Hz, Auto-Switching
- Projection Distance: 19.4" - 27"
- Projection Lens: F=2.5 - 3.26, F=20.91 - 32.62mm Manual Focus
- Projection Method: Front, Rear, Ceiling Mount, Tabletop
- Projection Screen Size: 85" - 115"
- Remote Control: IR Remote Control
- Throw Ratio: 0.27:1 (Distance/Width) - 5% Variance
- Uniformity: 80%
- Zoom Type: Fixed Lens
- Compatibility
- 3D Compatibility
- Side-By-Side: 1080i50 / 60, 720p50 / 60
- Frame-Pack: 1080p25, 720p50 / 60
- Over-Under: 1080p24, 720p50 / 60
- Computer Compatibility: SVGA, VGA, SXGA, UXGA, XGA, WXGA, HD, Mac
- Horizontal Scan Rate: 15.375 ~ 91.146 kHz
- Optional Wireless: Yes
- RoHS: Compliant
- Vertical Scan Rate: 24 - 85 Hz (120 Hz for 3D)
- Video Compatibility: NTSC, PAL, SECAM, SDTV (480i), EDTV (480p), HDTV (720p, 1080i/p)
- Physical
- Dimensions (HxWxD): 5" x 15" x 12.5"
- Security: Security Bar, Kensington Lock, Password Protection, Keypad Lock
