Tripp Lite B132-008A-2
8-Port VGA/Audio Extender Splitter

OUR PART #:  B132-008A-2

Our Price: $255.85
List Price: $344.00
You save 26%!
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

Tripp Lite B132-008A-2
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The Tripp Lite The B132-008A-2 8-Port VGA + Audio over Cat5/Cat6 Extender/Splitter works with a B132-100A or B132-100A-WP-1 remote receiver to split a VGA audio/video signal into nine separate signals—one local and eight remote. It’s ideal for digital signs, trade shows and other applications where the video source is located farther than conventional cables allow or that require multiple displays connected to one source.

The B132-008A-2 uses VGA cable (such as Tripp Lite’s P504-Series) to connect to the source and displays and Cat5e/6 cable to transmit to the remote receivers. For best results, use 24 AWG solid-wire N022-01K-GY (Cat5e) or N222-01K-GY (Cat6) cable.

When used with Tripp Lite’s B132-Series active remote receivers, the B132-008A-2 can extend a 1920 x 1440 (60 Hz) signal up to 500 feet and a 1024 x 768 (60 Hz) signal up to 1,000 feet. By daisy-chaining up to six units, one audio/video source can transmit to as many as 49 displays—48 remote and one local.

Add up to three B132-110A remote repeaters to each channel to fully extend the signal range or add more displays. You can extend a 1920 x 1440 (60 Hz) signal up to 500 feet or a 1024 x 768 (60 Hz) signal up to 1,000 feet from the first repeater in the chain to the last receiver.

The B132-008A-2 also delivers high-quality audio and copies EDID information from a connected display to ensure optimal compatibility. Easy to set up with no software or drivers to install. Mounts to a wall, rack or pole using the included hardware.

Tripp Lite B132-008A-2 Includes:

  • B132-008A-2 8-Port VGA + Audio over Cat5/6 Extender Splitter
  • External power supply (Input: 100–240V, 50/60 Hz, 0.5A; Output: 5V, 2A)
  • VGA + audio daisy-chain cable, 1 ft.
  • Mounting hardware
  • Owner’s manual

Tripp Lite B132-008A-2 Features:

  • Ideal for applications where the video source is located farther than conventional cables allow or that require multiple displays connected to one source
  • Splits one VGA + audio signal into 9 separate signals (8 remote, 1 local)
  • Tripp Lite B132-100A or B132-100A-WP-1 remote receiver required for each remote signal
  • Daisy-chain up to 6 units to extend the original audio/video signal to as many as 49 displays (48 remote, 1 local)
  • Connects to next link in chain with one Cat5/Cat6 cable, such as Tripp Lite 24 AWG solid-wire N022-01K-GY (Cat5e) or N222-01K-GY (Cat6) cable
  • Add up to 3 B132-110A remote repeaters to each channel to extend signal range or add displays
  • Extends a 1920 x 1440 (60 Hz) signal up to 500 ft. away from the audio/video source
  • Extends a 1024 x 768 (60 Hz) signal up to 1,000 ft. away from the audio/video source
  • Supports high-quality audio
  • Plug-and-play engineering—no software or drivers to download and install
  • Connects quickly to source and displays with VGA cable, such as Tripp Lite’s P504-Series
  • LEDs indicate at a glance when the unit is receiving power and a VGA signal from the source
  • Included mounting hardware lets you install the unit on a wall, rack or pole

Tripp Lite B132-008A-2 Specifications:

  • Physical:
    • Shipping Weight: 3.9 lbs
    • Unit Dimensions (HxWxD): 1.2" x 9.3" x 3.9"
    • Unit WeightL: 1.5 lbs
    • Color: Black
  • Communications:
    • Max 1024 x 768 Range: 1000 ft
    • Max 480P Range: 1000 ft
    • Max 1440 x 900 Range: 500 ft
    • Max 1080i Range: 500 ft
    • Max 1080P Range: 500 ft
    • Max 1920 x 1440 Range: 500 ft
    • Max 480i Range: 1000 ft
    • Max 640 x 480 Range: 1000 ft
    • Max 800 x 600 Range: 1000 ft
    • Max 1600 x 1200 Range: 500 ft
    • Max 1920 x 1200 Range: 500 ft
    • Max 720P Range: 500 ft
  • Connections:
    • Ports: 8
    • Side A:
      • Connector 1: HD15 (FEMALE)
      • Cnnector 2: 3.5MM (FEMALE)
    • Side B:
      • Connector 1: (8) RJ45 (FEMALE)
      • Connector 2: HD15 (FEMALE)
      • Connector 3: 3.5MM (FEMALE)
  • Poduct Warranty Period (Worldwide): 1-year limited warranty
