Product Overview

Sony's 5,000 lumen laser projector, the VPL-PHZ10 (WUXGA) is extremely easy to install, and expands upon Sony’s growing line of Z-Phosphor™ laser light source projectors. Offering improvements in lens shift range and function over conventional lamp projectors, making this model ideal for business and academic use. This class of projector is truly groundbreaking in a market currently dominated by lamp projectors – simplified installation and easy lens shift operation represent a great opportunity to try laser projectors for the first time.

The powerful Z-Phosphor laser light source is teamed with Sony's advanced BrightEra 3LCD projection engine to deliver extremely bright, detail-packed WUXGA-resolution images with a generous 5,000 lumens of brightness and rich, stable colors. This laser light source allows up to 20,000 hours* of virtually zero-maintenance operation without the worry of sudden lamp failures. An automated filter system cuts the hassle of regular dust cleaning. Near-zero maintenance needs are complemented by a range of energy-saving features, significantly driving down total lifetime ownership costs.

Constant Bright maintains consistent light output levels throughout the laser's 20,000 hours (at light output mode "Middle") recommended lifespan. Offering a stylish blend-in design and low fan noise, the VPL-PHZ10 fits smoothly into almost any environment — from academic institutions to corporate environments. Mount the projector at any angle, even on its side or upside down. Setup is easier than ever with a friendly new installation menu.

Features

  • Very high image quality with Sony's advanced BrightEra 3LCD projection engine and Z-Phosphor laser light source
  • The Z-Phosphor laser light source is coupled with Sony's acclaimed BrightEra 3LCD projection engine to ensure high, 5,000-lumen image brightness with vivid, natural color reproduction
  • Constant Bright maintains the same brightness throughout the 20,000 hours (at light output mode "Middle") recommended lifespan
  • Picture quality is boosted by advanced processing featured on Sony's home cinema projectors. Reality Creation uses a powerful pattern-matching database to optimize every pixel
  • Contrast Enhancer actively analyzes and refines dark and light image areas for sparkling highlights and rich, deep blacks
  • See fine detail in PC presentations, videos, or multimedia signage with WUXGA (1920 x 1200) 16:10 resolution
  • The advanced laser light source offers up to 20,000 hours* of operation without lamp exchange, reducing lifetime running costs compared with traditional projectors. (NOTE: *Actual hours may vary depending on usage environment)
  • Focus on great-looking images instead of arduous maintenance tasks: new automated filter cleaning system removes dust every 100 hours
  • Quick power On/Off dramatically cuts warm-up time after switch-on before you can start presenting at full brightness
  • Enjoy greater installation flexibility: position the projector freely at any angle — on its side or even upside down
  • Low fan noise ensures discreet, unobtrusive operation in quiet environments for academic and corporate use

Specifications

  • Optical:
    • Projection System: 3 LCD
    • Image Device: 3 LCD
    • Color Light Output: 5000 lumens
    • Light Output: 5000 lumens
    • Zoom Ratio: x 1.45 manual zoom
    • Throw Ratio: 1.28:1 to 1.88:1
    • Screen Coverage: 40" to 300" diagonal
  • Input/Output:
    • Composite Video In: RCA
    • Analog RGB/Component In: 15 pin HD
    • Digital In: HDMI (x2), HDBaseT (x1)
    • Network: RJ45
    • Variable Audio Out: Stereo mini
    • Remote Control: RS232C
    • USB: Type A, Type B
  • Electrical:
    • Native Resolution: 1920 by 1200 pixels
    • Video Resolution: 1080p
    • Acceptable Computer Signals: Up to 1920 by 1200
  • General:
    • Dimensions (WxHxD): 20" x 4.4" x 13.9"
    • Weight: 19.2 lbs
    • Power Requirements: 120 v ac

Note

*Actual hours may vary depending on usage environment.
