Epson PowerLite 5520W
5500 Lumens WXGA 3LCD Projector

OUR PART #:  POWERLITE-5520W

Our Price: $2,155.52
List Price: $2,199.00

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

Epson PowerLite 5520W
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

Epson's PowerLite 5520W widescreen installation projector is designed for large venues and delivers uncompromising image quality along with professional-grade reliability. Offering 3x Higher Color Brightness* than competitive models, Epson® 3LCD projectors ensure bright, vivid images. It features 5,500 lumens of color brightness and 5,500 lumens of white brightness¹, plus WXGA resolution with up to 15,000:1 contrast ratio. It pierces through, even in situations with high ambient light. Horizontal and vertical lens shift provides installation flexibility, while advanced digital connectivity, including HDBaseT™, ensures easy integration. Miracast® allows presenters to wirelessly mirror Android™ device screens. The projector also supports enterprise-level wireless security and remote network monitoring/control.

Epson PowerLite 5520W Includes:

  • PowerLite 5520W projector with lens cap
  • Power cable
  • Computer cable (VGA)
  • Projector remote control with batteries
  • User manual CD
  • EasyMP® software CD
  • Quick Setup Sheet
  • Registration card and lens lock screw

Epson PowerLite 5520W Features:

  • 3x Higher Color Brightness* and reliable performance — 3LCD, 3-chip technology
  • Look for 2 numbers —
    • The PowerLite 5520W has:
      • 5,500 lumens Color Brightness for accurate, vivid color¹
      • 5,500 lumens White Brightness for well-lit rooms¹
  • Crisp, detailed images — WXGA (1280 x 800) resolution with up to 15,000:1 dynamic contrast ratio
  • Installation flexibility — up to ±50 percent vertical and ±10 percent horizontal lens shift
  • Advanced connectivity — HDBaseT and 2x HDMI® inputs for easy integration with any system
  • Enterprise-level wireless security — the optional wireless LAN module (sold separately) supports robust wireless network security protocols that help keep information safe
  • Remote network monitoring and control — plus Message Broadcasting and built-in scheduling functions
  • Long-lasting lamp — up to 10,000 hours in ECO Mode²
  • Seamless integration tools — compatible with Crestron® RoomView® and Extron®

Notes:
* Color brightness (color light output) measured in accordance with IDMS 15.4. Color brightness will vary depending on usage conditions. The projectors used by a third-party lab for measuring color brightness were leading Epson 3LCD business and education projectors and leading 1-chip DLP projectors, based on NPD sales data for June 2013 through May 2014 and PMA Research sales data for Q1 through Q3 2013.

¹ Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.

² ECO Mode is up to 10,000 hours. Normal Mode is up to 5,000 hours. Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.

Epson PowerLite 5520W Specifications:

General:

  • Projection System: High-aperture Epson 3-chip 3LCD technology
  • Projection Method: Front / rear / ceiling mount
  • Driving Method: Epson Poly-silicon TFT Active Matrix
  • Pixel Number: 1,024,000 pixels (1280 x 800) x 3
  • Color Brightness - Color Light Output: 5500 lumens¹
  • White Brightness - White Light Output: 5500 lumens¹
  • Aspect Ratio: Supports 4:3, 16:9, 16:10
  • Native Resolution: 1280 x 800 (WXGA)
  • Display Performance:
    • NTSC: 480 line
    • PAL: 576 line
      (depends on observation of the multi-burst pattern)
  • Input Signal: NTSC/NTSC4.43/PAL/M-PAL/N-PAL/PAL60/SECAM/480i/576i/480p/576p/720p/1080i/1080p
  • Interfaces:
    • 1x HDBaseT
    • HDMI x 2 (1x MHL)
    • Computer: D-sub 15 pin x 1
    • Component Video: 1x BNC
    • Audio-in: 2x Mini stereo
    • Network: 1x RJ-45 100 Mbps
    • Serial: 1x RS-232c
    • USB: 1x Type A (for wireless module, service, firmware update, clone settings)
    • 1x Type B (firmware update)
    • 1x Hardwire remote jack
    • Monitor Out: 1x D-sub 15 pin
    • 1x Audio Out
  • Fan Noise:
    • Normal mode: 38 dB
    • ECO mode: 28 dB
  • Resize: 640 x 480, 800 x 600, 1280 x 1024, 1400 x 1050
  • Lamp Type: 300 UHE
  • Lamp Life:
    • Normal mode: Up to 10,000 hours²
    • ECO mode: Up to 5000 hours²
  • Brightness Uniformity: 87%
  • Throw Ratio Range: 1.26 – 2.30
  • Size - projected distance: 30" – 300"
  • Keystone Correction:
    • Horizontal: ±30 degrees
    • Vertical: ±30 degrees
  • Contrast Ratio: High Brightness, Dynamic Mode: 15,000:1
  • Color Processing: 10-bit
  • Color Reproduction: Up to 1 billion colors
  • Physical:
    • Dimensions:
      • Including feet (W x D x H): .5" x 13.9" x 6.2"
      • Excluding feet and lens (W x D x H): 18.5" x 12.6" x 5.2"
    • Operating Environment Temperature: 32° to 113° F (0° to 45° C)
    • Weight: Weight with standard Lens 15.2 lbs
  • Security:
    • Security Cable Hole
    • Lens Lock
    • Kensington® lock provision
  • Power:
    • Power Supply Voltage: 100 – 240 V ±10%, 50/60 Hz AC
    • Power Consumption:
      • Normal mode: 462 W
      • ECO mode: 324 W
      • Communication on: 3.0 W standby
      • Communication off: 0.5 W standby

Effective Scanning Frequency Range:

  • Pixel Clock, Horizontal,Vertical:
    • Pixel Clock:13.5 MHz – 162 MHz (up to UXGA 60 Hz)
    • Horizontal: 15 KHz – 92 KHz
    • Vertical: 50 Hz – 85 Hz

Remote Control:

  • Features: Power, Source Search Selection, Computer, Video, A/V Mute, Freeze, User ID, Auto, Aspect, Color Mode, Number, Page Up & Down, E-Zoom, Volume, Help, Menu, Enter, Esc, and Pointer Functions
  • Operating Distance: 49ft
  • Operating Angle:
    • Right / Left:
    • Front: ±60 degrees
    • Rear: ±30 degrees
    • Upper / Lower:
    • Front: ±20 degrees
    • Rear: +10 to +45 degrees

Projection Lens:

  • Type: Manual focus / zoom
  • F-number: 1.5 – 2.15
  • Focal Length: 21.34 mm – 37.99 mm
  • Zoom Ratio: Optical zoom 1.0x – 2.0x
  • Lens Shift:
    • Horizontal: ±10 degrees
    • Vertical: ±50 degrees

Notes:
* Color brightness (color light output) measured in accordance with IDMS 15.4. Color brightness will vary depending on usage conditions. The projectors used by a third-party lab for measuring color brightness were leading Epson 3LCD business and education projectors and leading 1-chip DLP projectors, based on NPD sales data for June 2013 through May 2014 and PMA Research sales data for Q1 through Q3 2013.

¹ Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.

² ECO Mode is up to 10,000 hours. Normal Mode is up to 5,000 hours. Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.
