Community R.5COAX66W
12-inch Compact Full-Range Coaxial Two-Way Speaker in White


The Community R.5COAX66W is high fidelity, two-way...
Learn More
Our Price: $942.00
Write the first review.
Community R.5COAX66W
Usually ships in 7-14 business days.
Need it sooner? Call us!

Related Products

The Community R.5COAX66W is high fidelity, two-way, full-range loudspeaker system that's engineered to provide quality full-range sound in a variety of outdoor and indoor applications. Its smooth frequency response, wide audio range, and high efficiency ensure both high fidelity music reproduction and superb projection of clear, intelligible speech with very low distortion. Five-year limited product warranty; fifteen-year enclosure warranty.

Community R-Series
All the way from the compact R.25 and R.5 on up to the powerful R6-51, there is a Community R-Series speaker that's right for every installation. Highly weather-resistant for outdoor usage, but very appropriate for indoors as well, the R-Series delivers exceptional voice clarity and sound projection capability. R-Series systems can be found in the world's premier amusement parks, sports arenas, cruise ships, and race tracks, along with countless university and high school sports fields. All R-Series loudspeaker enclosures are warranted for structural integrity for 15 years.

Community R.5COAX66W Includes:

  • (1) R.5COAX66W unit
  • (1) Yoke bracket, White
  • (1) Aiming strap

Community R.5COAX66W Features:

  • Weather-treated drivers and crossovers
  • Included zinc-rich epoxy dual-layer powder-coated steel grille and yoke
  • Weather and UV-resistant rotomolded enclosure with integral mounting points
  • High efficiency, high fidelity and high power passive crossover

Community R.5COAX66W Specifications:

  • Loudspeaker Type: 2-way, coaxial, weather-resistant, full-range
  • Operating Range: 80 Hz to 18 kHz, 90 Hz to 12.5 kHz (±3.5 dB)
  • Max Input Ratings: 200W continuous, 500W program, 40 volts RMS, 89 volts momentary peak
  • Recommended Power Amplifier: 420W to 600W @ 8 ohms
  • Sensitivity (1W/1m):
    • 98 dB SPL (100 Hz to 13 kHz 1/3 octave bands)
    • 97 dBSPL (250 Hz to 4 kHz speech range)
  • Maximum Output: 121 dB SPL / 128 dB SPL (peak)
  • Nominal Impedance: 8 Ohms
  • Minimum Impedance: 4.2 Ohms @ 9.9 kHz, Nominal –6dB
  • Beamwidth:
    • H: 60° (+20° / -6°, 1.6 kHz to 12.5 kHz)
    • V: 60° (+20° / -3°, 1.6kHz to 12.5 kHz)
  • Axial Q / DI: 15.2 / 11.8, 1.6 kHz to 12.5 kHz
  • Crossover Frequency: 2 kHz
  • Recommended Signal Processing: 60 Hz high pass filter
  • Drivers:
    • LF: 1 x 12”
    • HF: 1 x 1” exit titanium free, Ferrofluid-cooled
  • Driver Protection: DYNA-TECH protection circuitry
  • Input Connection: 12ft (4m) SJOW #16 gauge
  • Controls: None
  • Enclosure: Rotomolded LLDPE, White
  • Mounting/Rigging Provisions: (5) 3/8-16 rigging points
  • Grille: 3-layer WeatherStop™, White (Zinc-rich epoxy dual-layer powder coated perforated steel grille, foam, woven poly mesh)
  • Required Accessories: 24 dB/Oct high pass filter (consult your Sales Pro for more information)
  • Optional Accessories (sold separately): PMB Series pole mount brackets
  • Dimensions (HxWxD): 16" x 16" x 15.94" (406.4 x 406.4 x 404.88mm)
  • Weight:
    • Product: 35 lbs (15.9 kg)
    • Shipping: 42 lbs (19.1 kg)
  • Environmental Performance: IEC529 IP54W rating with a minimum 5-degree downward aiming angle
