Biamp R.5COAX66B 12" 2-Way Full Range Coaxial Speaker, Black

OUR PART #: R.5COAX66B MFR #: R.5COAX66B

Copied to clipboard

The R.5COAX66B from Community is a high fidelity, two-way, full-range loudspeaker system made to deliver quality, full-range sound in a variety of outdoor and indoor situations. ...Read more

Biamp R.5COAX66B 12" 2-Way Full Range Coaxial Speaker, Black Image 1
Biamp R.5COAX66B 12" 2-Way Full Range Coaxial Speaker, Black Image 2
Biamp R.5COAX66B 12" 2-Way Full Range Coaxial Speaker, Black
Our Price: $1,486.00

SPECIAL FINANCING AVAILABLE

Synchrony Music & Sound Card
$42/mo* with 36 month financing. ‡
Limited Time. Learn How
Item usually available to ship in 9-12 Business Days. Please call for up-to-date information on product availability.

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Accessories

Product Overview

The R.5COAX66B from Community is a high fidelity, two-way, full-range loudspeaker system made to deliver quality, full-range sound in a variety of outdoor and indoor situations. With its wide range, smooth frequency response, and high efficiency, you can be assured that both high-fidelity music reproduction and superb projection of clear, intelligible speech with very low distortion. They include a five-year limited product warranty, as welll as a fifteen-year enclosure warranty.

All the way from the compact R.25 and R.5 up to the powerful R6-51, there is a Community R-Series that's right for every installation. Highly weather-resistant for outdoor applications, but very appropriate for indoor use as well, the R-Series provides exceptional voice clarity and sound projection capability. R-Series systems are found in the world’s premier amusement parks, sports arenas, cruise ships, and race tracks as well as countless university and high school sports fields. All R-Series loudspeaker enclosures are warranted for structural integrity for 15 years.

Community R.5-COAX-66B Includes:

  • (1) R.5COAX66B unit
  • (1) Yoke bracket, Black
  • (1) Aiming strap

Community R.5-COAX-66B Features:

  • Weather-treated drivers and crossovers
  • Included zinc-rich epoxy dual-layer powder-coated steel grille and yoke
  • Weather and UV-resistant rotomolded enclosure with integral mounting points
  • High efficiency, high fidelity and high power passive crossover

Community R.5-COAX-66B Specifications:

  • Loudspeaker Type: 2-way, coaxial, weather-resistant, full-range
  • Operating Range: 80 Hz to 18 kHz, 90 Hz to 12.5 kHz (±3.5 dB)
  • Max Input Ratings: 200W continuous, 500W program, 40 volts RMS, 89 volts momentary peak
  • Recommended Power Amplifier: 420W to 600W @ 8 ohms
  • Sensitivity (1W/1m):
    • 98 dB SPL (100 Hz to 13 kHz 1/3 octave bands)
    • 97 dBSPL (250 Hz to 4 kHz speech range)
  • Maximum Output: 121 dB SPL / 128 dB SPL (peak)
  • Nominal Impedance: 8 Ohms
  • Minimum Impedance: 4.2 Ohms @ 9.9 kHz, Nominal –6dB
  • Beamwidth:
    • H: 60° (+20° / -6°, 1.6 kHz to 12.5 kHz)
    • V: 60° (+20° / -3°, 1.6kHz to 12.5 kHz)
  • Axial Q / DI: 15.2 / 11.8, 1.6 kHz to 12.5 kHz
  • Crossover Frequency: 2 kHz
  • Recommended Signal Processing: 60 Hz high pass filter
  • Drivers:
    • LF: 1 x 12”
    • HF: 1 x 1” exit titanium free, Ferrofluid-cooled
  • Driver Protection: DYNA-TECH protection circuitry
  • Input Connection: 12ft (4m) SJOW #16 gauge
  • Controls: None
  • Enclosure: Rotomolded LLDPE, Black
  • Mounting/Rigging Provisions: (5) 3/8-16 rigging points
  • Grille: 3-layer WeatherStop™, Black (Zinc-rich epoxy dual-layer powder coated perforated steel grille, foam, woven poly mesh)
  • Required Accessories: 24 dB/Oct high pass filter (consult your Sales Pro for more information)
  • Optional Accessories (
  • Dimensions (HxWxD): 16" x 16" x 15.94" (406.4 x 406.4 x 404.88mm)
  • Weight:
    • Product: 35 lbs (15.9 kg)
    • Shipping: 42 lbs (19.1 kg)
  • Environmental Performance: IEC529 IP54W rating with a minimum 5-degree downward aiming angle
