Community R.35-3896W
Full-Range 3-Way 8-Inch Weather-Resistant Loudspeaker in White

OUR PART #:  R.35-3896W

The innovative triaxial design on the Community R.35-3896W delivers musical quality and detail better than many larger loudspeakers.
Learn More
Our Price: $677.00

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Community R.35-3896W
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The innovative triaxial design on the Community R.35-3896W delivers musical quality and detail better than many larger loudspeakers. Community's exclusive MultiSource Waveguide™ system sums dual midrange compression drivers and a 1-inch exit HF driver into a single point source with a 90° x 60° pattern of dispersion. It's designed to offer premium quality music reproduction with exceptional clarity, and is an excellent choice for sightline-friendly, medium-projection sports venue music systems as a flatter, higher output alternative to the Community R.25. It features an attractive, paintable ABS enclosure with included 200W autoformer and Voice/Music switch.

Community R-Series
From the compact R.25 and R.5 models on to the powerful R6-51, there's a Community R-Series made for every installation. Highly weather-resistant for outdoor usage, but very much at home indoors as well, the R-Series provides remarkable voice clarity and sound projection capability. R-Series systems are found in the world’s premier amusement parks, sports arenas, cruise ships, and race tracks as well as countless university and high school sports fields. All R-Series loudspeaker enclosures are warranted for structural integrity for 15 years.

Applications include:

  • Theme and Amusement Parks
  • Outdoor Entertainment Centers
  • Malls, Fairgrounds, Race Tracks
  • Multipurpose Indoor/Outdoor Venues
  • Stadiums and Arenas
  • Swimming pools
  • Athletic Fields
  • Convention Centers
  • Cruise Ships
  • Factories

Community R.35-3896W Features:

  • Excellent musicality and intelligibility, low distortion, and high sensitivity and output
  • Weather-resistant, compact, matte finish paintable high impact ABS plastic modified-trapezoidal enclosure
  • NeverWet™ treated grille and LF driver cones, polymer HF and MR diaphragms, and moisture-sealed crossover
  • Corrosion-resistant zinc-rich epoxy dual-layer powder coated (DLPC) steel grille and low-profile yoke
  • Innovative MultiSource Waveguide™ (MSW) horn design for high frequency and dual midrange drivers
  • 200W autoformer (standard)
  • White finish standard. Custom colors available upon request (contact your Sales Pro)
  • Five-year product warranty / Fifteen-year enclosure warranty

Community R.35-3896W Specifications:

System:

  • Loudspeaker Type: Full-range, three-way, triaxial, weather-resistant
  • Operating Range: 80 Hz to 16 kHz (-10 dB)
  • Frequency Response: 120 Hz to 12.5 kHz (-3 dB)
  • Nominal Beamwidth (-6dB): 90° x 60° , 1.6 kHz to 10 kHz
  • Max Input Ratings:
    • 400W RMS, 800W Program
    • 56 volts RMS, 113 volts momentary peak
  • Autoformer Taps;
    • 70V: 200W, 100W, 50W, 25W, and low impedance
    • 100V: 200W, 100W, 50W
  • Maximum Output:
    • Music: 124 dB (130 dB peak)
    • Speech: 126 dB (132 dB peak)
  • Sensitivity (1W / 1m) Free Space SPL:
    • Music:
      • 98 dB (125 Hz - 10 kHz)
      • 97 dB (250 Hz - 4 kHz)
    • Speech:
      • 100 dB (125 Hz - 10 kHz)
      • 99 dB (250 Hz - 4 kHz)
  • Nominal Impedance:
    • Music: 8 ohms, 6 ohms @ 9 kHz minimum
    • Speech: 8 ohms, 4.1 ohms @ 8 kHz minimum
  • Axial Q / DI: 11.6/10.7, 1.6 kHz to 10 kHz
  • Crossover Frequency: 850 Hz, 2.7 kHz
  • Recommended High Pass: 80 Hz 24 dB / Octave
  • Recommended Amplifier : 800W to 1200W at 8 Ohms
  • Triaxial Transducers:
    • Low Frequency: 1 x 8" Carbon ring NeverWet™* treated cone, 3" VC
    • Middle Range: 2 x 2.35" MultiSource Waveguide™ compression
    • High Frequency: 1 x 1" exit compression

* NeverWet is a registered trademark of NeverWet, LLC.

Physical:

  • Input Connection: NL4 Speakon-type connector for low impedance operation only; and 7-position terminal strip for low impedance or constant voltage operation
  • Controls: Music / speech switch, 70V/100V operation jumper
  • Enclosure: ABS plastic, matte finish, paintable
  • Finish: White (standard)
  • Mounting/Rigging Provisions: Two (2) M8 rigging points, zinc-rich epoxy DLPC yoke, included integral safety cable mounting point
  • Grille: 3-layer Weather-Stop™ featuring NeverWet™ treated polyester mesh, foam, zinc-rich DLPC perforated steel color-matched to enclosure
  • Input Panel Weather Cover: Color-matched ABS plastic with 13.5mm ID gland nut installed in .82" knockout
  • Dimensions (HxWxD): 11" x 13" x 13.5" (279 x 330 x 343 mm)
  • Loudspeaker Weight:
    • Product: 34 lbs (15.4 kg) with included yoke
    • Shipping: 40 lbs (18.1 kg)
  • Environmental: IP55W per IEC 529 at the recommended 5° down-tilt, designed to MIL-STD-810G

NOTE: All wattage figures are calculated using the rated impedance.

Community strives to improve its products on a continual basis. Specifications are therefore subject to change without notice.
