Panasonic TH55LFV60U
55" LED Display Ultra Narrow Bezel Display

OUR PART #:  TH55LFV60U

Our Price: $4,590.15
List Price: $5,739.00
You save 20%!
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

Panasonic TH55LFV60U
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The Panasonic TH-55LFV60U 55" Ultra Narrow Benzel LCD Display features an extensive display menu that allows you to very easily choose from a wide selection of display modes to suit different content, video sources, and lighting environments to achieve optimal results.

Panasonic TH-55LFV60U Features:

  • Optimized image modes
  • Multi-screen video synchronization
  • High-performance imaging engine
  • Multi-screen imaging synciing via USB and changing content via LAN
  • Dedicated video-wall mounting system
  • Efficient 24/7 reliablility in landscape or protrait mode
  • Factory-matched and pre-calibrated color
  • Ultra-narrow bezel for seamless video walls

Panasonic TH-55LFV60U Specifications:

  • Model: TH-55LFV60
  • Display Panel:
    • Screen Size (Diagonal): 55" (1387 mm)
    • Aspect Ratio: 16:9
    • Panel Type: IPS / Direct-LED
    • Resolution: 1920 x 1080
    • Brightness (Typ): 700 cd/m2
    • Contrast Ratio: 1400:1
    • Response Time: 12 ms (G to G)
    • Dynamic Contrast Ratio: 500000 : 1
    • Viewing Angle (Horizontal/Vertical): 178°/178° (CR=10)
    • Panel Surface Treatment: Anti-Reflection
  • Connection Terminal:
    • VIDEO In: BNC x 1 (Shared with Component In)
    • Audio In (L/R): Stereo Mini-Jack (M3) x 1 (Shared with Component/RGB In)
    • HDMI In: HDMI Type A Connector x 2
    • Component/RGB In: BNC x 1 (Shared with VIDEO In)
    • Audio In (L/R): Stereo Mini-Jack (M3) x 1 (Shared with VIDEO In)
    • DVI-D In: DVI-D 24-pin x 1
    • DVI-D Out: DVI-D 24-pin x 1
    • Audio In (L/R): Stereo Mini Jack (M3) x 1 (Shared with PC In)
    • PC In: Mini D-Sub 15-pin x 1 (Female)
    • Audio In (L/R): Stereo Mini Jack (M3) x 1 (Shared with DVI-D In)
    • Audio Out: Stereo Mini Jack (M3) x 1
    • USB: USB Type A Connector (DC 5 V/1 A) x 1 (USB 3.0 Not Supported)
    • Sereial In/Out: D-Sub 9-pin x 1/1, RS-232C Compatible
    • IR In/Out: Stereo Mini Jack (M3) x 1/x 1
    • LAN: RJ45 x 1 (10BASE-T/100BASE-TX, Compatible with PJLink™)
  • Audio:
    • External Speaker: 8 O, 20 W [10 W + 10 W]
  • Electrical:
    • Power Requirements: 100-240 V AC, 50/60 Hz
    • Power Consumption: 300 W (U) / 290 W (W)
    • Stand-by Conditions: 0.5 W
  • Mechanical:
    • Dimensios (WxHxD): 47.8" x 26.9" x 3.7" (1213 x 684 x 95 mm)
    • Bezel to Bezel: 0.14" (3.5 mm)
    • Weight: Approx. 66.1 lbs. (30 kg)
  • Installation Requirement:
    • Orientation: Landscape/Portrait
    • Tilting Angle: Vertical only*1
  • Operating Environment:
    • 32°F to 104°F (0°C to 40°C)*2/ 32°F to 95°F (0°C to 35°C)*3
    • Humidity: 10% to 90% (Non Condensation)
  • Operating Time*4: 24 h/day
  • Regional Spec Sheets:
    • Americas: TH-LFV60U
    • Europe, CIS, Asia, Middle East, Oceania, Africa: TH-LFV60W

*1: Please contact your sales representative with regard to the tilt angle before installation.
*2: For up to 1400 m (4593 ft) altitude.
*3: For between 1400 m (4593 ft) and 2800 m (9186 ft) altitude.
*4: In case of long time, the moving image is recommended to be displayed. If you display a still picture for an extended period, the image retention might remain on the screen. However, image retention can gradually disappear by displaying a moving images.
