EAW MK8196I-WHITE White 2 Way Passive Speaker

The EAW MK8196i two-way loudspeaker system sets the new standard in installation performance by solving the chronic problems of compact two-way loudspeakers. Yet it’s size is actually smaller than many of the compact two-ways it outperforms.

The HF horn loading the 1" exit/1.5" voice coil compression driver is larger than most traditional compact two-way horns. This extends pattern control lower into the midrange than would otherwise be possible and allows the horn’s pattern to overlap the woofer’s pattern in the critical crossover area.

Advanced beamwidth matching crossover point selection transitions between the subsystems exactly where the HF horn’s 90° (h) x 60° (v) coverage pattern matches the woofer’s pattern. This eliminates the beamwidth mismatch that creates off-axis voids in the crossover area of traditional two-way systems.

The internal passive crossover/filter network uses complex, asymmetrical slopes to integrate the subsystems and goes beyond merely dividing the signal to perform critical equalization functions.

Product is WHITE in Appearance

EAW MK8196I Features:

• System includes an 8" woofer and a 1" exit/1.5" voicecoil compression driver on a 90° x 60° CD horn
• Internal passive crossover/filter network allowspowering by a single amp channel while smoothing power response
• Beamwidth optimized crossover points eliminateoff-axis voids through crossover
• User-rotatable horn lets you “rotate the enclosure around the horn” tomount them vertically or horizontally

EAW MK8196I Specifications:

• SKU: 0031663
• Subsystem:
  • Transducer: LF – 1x 8 in. cone; HF – 1x 1" exit/1.5" voice coil compression driver on CD horn
  • Loading: LF – Vented; HF – Horn-loaded
• Operating Mode:
  • Amplifier Channels: Single-amp LF/HF
  • External Signal Processing: High pass filter; DSP w/2-way filters
• Operating Range (-10 dB, Hz): 60Hz – 18KHz
• Axial Sensitivity (1W @ 1m, dB SPL): Full Range: 95
• Power Handling/Impedance (Watts @ Ohms): Full Range:300 @ 8
• Calculated Maximum Output Peak (dB SPL): Full Range:126
• Calculated Maximum Output Long Term (dB SPL): FullRange: 120
• Nominal Coverage:
  • Horizontal: 90°
  • Vertical: 60°
• Powering: Full range
• Dimensions (HxWxD): 19.75" x 11.75" (Front) x 6.00"(Rear) x 11.03" (502 x 299 x 152 x 280 mm)
• Trap. Angle (degrees per side): 22.5°
• Weights:
  • Net: 31 lbs (14.1 kg)
  • Shipping: 34 lbs (15.5 kg)
