K-Array Tornado-KTL2 2" Point Source Compact Aluminum Speaker with RGB LED, Black

OUR PART #: KTL2

Copied to clipboard

The professional Tornado series is a miniature sound source designed for high-quality distributed systems. ...Read more

K-Array Tornado-KTL2 2" Point Source Compact Aluminum Speaker With RGB LED, Black Image 1
K-Array Tornado-KTL2 2" Point Source Compact Aluminum Speaker With RGB LED, Black Image 2
K-Array Tornado-KTL2 2" Point Source Compact Aluminum Speaker With RGB LED, Black Image 3
K-Array Tornado-KTL2 2" Point Source Compact Aluminum Speaker With RGB LED, Black
No longer available at Full Compass
We've left this page up for reference only.

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Accessories

Product Overview

The professional Tornado series is a miniature sound source designed for high-quality distributed systems. Housed in a compact aluminium enclosure, the KTL2 audio speakers are suitable for space sensitive and architectural design installations, even in ceiling and wall mount. The KTL2 is a turnkey and professional loudspeaker solution; designed as small passive audio speakers that can be easily converted into self-powered devices by inserting the KA1-T2H 12V/24V amplifier module. The KTL2 comes with a wall bracket for fixed installations or surface applications while the KTL2C and KTL2CW models come with a ceiling brackets for ceiling mounts.

K-array KTL2 Features:

  • Single 2” long excursion, full range driver
  • Wide range frequency response
  • Integrated 4-pin Phoenix connector
  • Double voice coil driver for variable impedance 8-32Ohm
  • Ultra strong, small and compact aluminium chassis
  • Integrated RGB LEDs

K-array KTL2 Specifications:

  • Acoustics:
    • Power handling: 18W
    • Impedance: 8 Ohm - 32 Ohm
    • Frequency range (-10 dB): 150 – 18 kHz
    • Maximum SPL: 101 dB (cont.) – 107 dB (peak)
  • Coverage:
    • Horizontal: 90°
    • Vertical: 90°
  • Crossover:
    • Type: External cross over required
    • Frequency: 150Hz 24dB/Oct minimum required
  • Transducers:
    • Full-range: 2” Neodymiun magnet Woofer with 2 voice coils of 0.8”
    • Impedance: 2 x 16 Ohm
  • Power Audio Input:
    • Connectors: 4-pin Phoenix connector
    • Wiring: VoiceCoil A=1+ 1-; VoiceCoil B=2+ 2-
  • LED Connections:
    • Connectors: 4-pin Phoenix connector
  • Physical:
    • Dimensions: 110 x 75 x 70 mm (4.33 x 2.95 x 2.76")
    • Weight: 0.54 Kg (1.19 lb)
