Contemporary Research Co. CRC-QMOD-SDIHDMI
Dual-channel RF or IPRV Encoder with SDI and HDMI Inputs


Contemporary Research's CRC-QMOD-SDIHDMI dual-program QIP-SDI HDMI, with one SDI and one HDMI input, sets a new standard for sports, motion and digital signage encoding.
Learn More
Our Price: $2,562.87
List Price: $2,700.00
You save 5%!
Write the first review.
Contemporary Research Co. CRC-QMOD-SDIHDMI
Usually ships in 7-14 business days.
Need it sooner? Call us!

Related Products

Contemporary Research's CRC-QMOD-SDIHDMI dual-program QIP-SDI HDMI, with one SDI and one HDMI input, sets a new standard for sports, motion and digital signage encoding. Dual hardware scalers accept content up to 1080p, shapes digital signage for edge-to-edge presentation, and compensates for non-broadcast and PAL refresh rates. Encoding as MPEG2 or H.264, the QMOD-SDI HDMI can output the content as two SPST Multicast or Unicast IPTV streams. Options include dual-language SAP audio, easy front-panel setup and alternate audio and NTSC video inputs. Web setup, monitoring, and firmware updates are available via USB and Ethernet ports. Two-across mounting offers up to four programs per rack space, with the ability to mix models to handle HDMI, SDI, and NTSC video sources.

Contemporary Research CRC-QMOD-SDIHDMI Includes:

  • PS12-2 Switching power supply
  • 2A 12 VDC
  • standard AC cord for power strips

Contemporary Research CRC-QMOD-SDIHDMI Features:

  • Sources:
    • HD-SDI input, 3G Level A 1080p and 1080i/720p 59.94/60 Hz HD-SDI, and SD-SDI 480i widescreen/4:3 video; also accepts embedded 608/708 captioning and AES, PCM and AC-3 audio
    • HDMI input (non-encrypted), 480p to 1080p, embedded PCM audio, pass-through AC-3
    • Two Composite/CC video inputs for encoding, captioning, or EAS use
    • Two analog Stereo and two SPDIF coax audio inputs
  • Encoding:
    • Creates up to two high-definition SPST Unicast or IPTV streams, encoded as H.264 or MPEG2
    • Converts stereo and PCM to stereo AAC or MP12, passes through or AC-3 and AAC
    • Can create SAP dual-language audio for each program
    • Accepts 608/708 embedded captioning, decodes Line 21 captioning from composite video inputs
    • Dual hardware scalers accept up to1080p 3G video, including 60/30 Hz, and PAL formats, and can deliver programs at a scled or native resolution
    • Dual-program operation is standard
  • Operation:
    • Sets up with front-panel buttons and easy to use menus, including inputs, encoding, channel, and RF options.
    • Onboard Web page for setup and monitoring, also accessible from front-panel USB port - an Ethernet connection is not required
    • Updates firmware via USB and Ethernet
    • Fan cooled, with adjustable speed
    • Saves power and rack space using efficient design
    • Includes compact switching power supply
    • Mounts in optional 1RU single (RK1) or dual (RK2EZ) 19” rack kits
    • Meets RoHS safety and California energy standards

Contemporary Research CRC-QMOD-SDIHDMI Specifications:

  • Physical:
    • 8.5” [216mm] wide x 1.73” [62mm] height (1RU) x 6.0” [153mm] deep
    • 1.5 lbs [0.68kg]
    • +32° to 122° F operating temperature, convection cooled
    • Rack mounting for one or two units side-by-side optional (RK1, RK2EZ)
    • For HRF Half-Racks, use the RK2EZ kit to mount each tuner
    • Fan cooled, with adjustable speed
  • Scaling:
    • Dual hardware scalers
    • Accepts 1080p - 480i/576i and VGA resolutions, 29.97 - 60 Hz US and PAL refresh rates
    • Edge to edge presentation with zoom, shrink and X/Y axis positioning
    • Auto-sync or sales to fixed output resolution, 1080p scaled to 1080i
  • Encoding:
    • H.264 or MPEG2 for HD, MP@ML for SD, 1080i, 720p, 576i, 480p, and 480i output resolution
    • MPEG 2 Video Encoding bitrate 10-25 Mbps, HD, 5-6 Mps 480i, or variable bitrate
    • H.264 Video Encoding bitrate 5-12 Mbps, HD, 2-3 Mps 480i, or variable bitrate
    • AES, PCM or analog audio output as MPEG1 Layer2 or AAC
    • Pass-through AC-3 audio
  • Front Panel:
    • Select and directional buttons for menu setup
    • Menu LCD, Blue with 2 lines of 20 white characters each
  • Back Panel:
    • Power:
      • 2.1mm coaxial jack (inside center conductor positive)
      • 1.1A maximum, 11.5 to 13.5 VDC, 12 VDC typical
    • EAS: 3 GPI Pins for latching control, SW(NO) for closure, V+ 5-12 VDC, Ground
    • Ethernet: RJ-45 GigE Ethernet connector for IP control, updates, Unicast/Multicast IPTV and internal Web page
    • SDI Inputs BNC Female
      • SD-SDI @ 270Mb/s, HD-SDI @ 1.485Gb/s, 3G SDI Level A @ 2.970Gb/s
      • Coax cable auto-equalizer for SD up to 460m, HD up to 230m (RG6)
      • Resolutions 1080p at 59.94Hz, 1080i/720p at 59.94/60Hz, or SD 480i at 29.97Hz
      • Accepts SDI embedded Stereo/AC-3/AAC 48KHz audio
      • Widescreen option for 480i
    • HDMI: (non-HDCP), up to 1080p, embedded PCM and AC-3 audio
    • Composite Video/CC Inputs: RCA female  NTSC/PAL(480i/576i), 29.97 Hz, supplies line 21 Captioning
    • Audio Inputs:
      • Two coax SPDIF digital audio inputs
      • Analog L and R: 2 stereo mini jacks
      • Inputs assignable to video inputs
