Product Overview
The Elation Professional M2GO HD has a large footprint and small built-in touchscreen. The M2GO HD offers a professional level of features in a portable package and has been developed with cost, ergonomics, feature set, size and weight in mind. The M2GO HD is a unique, portable and powerful lighting console.
Elation Professional M2GO-HD Includes:
- 1.5 m power cable, EU (Schuko), 3-pin IEC
- 1.5 m power cable, US, 3-pin IEC
- MW 12 VDC 5 A external PSU
- LED desklight, angular XLR, 13": P/N 91613090
- Elation One-Key: ShowDesigner 6™ Lite 3D Visualizer 180-day trial
- M-PC Pro with 64 Universe License
- M2GO HD dust cover
Elation Professional M2GO-HD Features:
- High resolution folding capacitive multi-touchscreen
- Integrated Industrial high speed processing
- 3.5” touchscreen for fast and direct parameter access
- 8 digital encoders for parameter control
- 8 customizable function keys
- 4x DMX Universes direct from the console; up to 20 Universes via Artnet and sACN without external processors
- Controls up to 10240 parameters
- Built-in 2D visualizer for selection and real-time visualization
- Customizable Graphical User Interface with context sensitive toolbars and integrated Help menu
- Powerful effects engine
- 1000 cuelists with fader control
- 1000 cuelists with playback control buttons
- Parallel execution of multiple cuelists
- Submaster, Groupmaster and Override functionality
- Parameter and Time-fanning functionality
- Auto update for presets and cues
- On-the-fly global timing adjustments
- M-Series Manager Software for programming and triggering via time and calendar schedules, RS232 and IP triggers
- Multiple wing attachment (M-Series Modules)
- MaxNet synchronized programming and playback support
Elation Professional M2GO-HD Specifications:
- Physical:
- Length: 11.9" (300 mm)
- Width: 21.3" (540 mm)
- Height: 3.9" (99 mm)\
- Weight: 11.5 lbs. (5.2 kg)
- Control and Programming:
- Protocol: DMX512A (RDM), Artnet2, sACN
- 4 physical DMX ports
- 20 DMX universes integrated
- No limit to number of DMX channels per fixture
- Extensive fixture library for all known manufacturers
- 65000 presets for each group of functions (P/T, color, gobo, etc.)
- Effect generator for automated programming of complex effects
- Customizable highlight and lowlight function to identify individual fixtures
- Relative or absolute programming
- Fan function for all channels (including timing parameters)
- On-the-fly global timing changes
- Virtual cuelists
- Macros
- Wait, follow and link cues
- HTP, LTP, chase, timecode, submaster and group master playback functionality
- Individual parameter timings Intuitive patch feature
- Fixture type cloning
- All channels with 16-bit resolution
- Control/User Interface:
- Main playback interface: Ten 60 mm playback faders, each with four function-assignable buttons
- Eight customizable multi-function keys
- Playback Select button
- Master Go section with Go, Pause, Snap and Release
- Four digital rotary encoders with push function and status LED for fixture parameter control
- 3.5” touchscreen for parameter groups, effect parameters, fanning and global timings and button
- Built-in 2D visualizer for selection and real-time visualization Grand master rotary fader
- Blind/preview button
- Customizable highlight/lowlight function
- Customizable parameter defaults
- Next/last fixtures/groups
- Large command keys
- Playback:
- Assign a cue, cuelist or effect to any playback fader
- 500 playback banks, each containing 10 playbacks
- 100 pages of 100 playbacks activated by touchscreen button
- No limit to cues per cuelist
- Full 16-bit fading for high-resolution fixtures
- Individual fade in/fade out times for all playbacks
- Manual override available at all times
- Live 0-1000% override of global cue timings
- Live programmer timing (“Sneak”)
- Cuelists can be executed in tracking or non-tracking mode
- Hardware:
- Industrial 15.6 inch TFT 16:9 touchscreen (1376x768 pixels)
- 3.5" RGB touchscreen
- 64 GB SSD storage drive
- Industrial motherboard with Intel Quad-Core processor
- 8 GB RAM
- Integrated graphics processor
- Software:
- Windows 10 Embedded OS
- OS installation by USB 3.0 storage device
- Show backup on hard disk or USB storage device (not included)
- Support for ELO and Windows USB touchscreens
- Connections:
- 4 x DMX universe outputs: 5-pin locking XLR
- External monitor screen: VGA and HDMI
- Artnet/sACN for up to 20 DMX universes in total: Gigabit
- RJ-45 MaxNet controller link: Gigabit RJ-45
- Storage media/hardware peripherals: USB 3.0
- Built-in Internal MIDI in/out/thru (MIDI show control, MIDI notes, MIDI timecode)
- Built-in Internal SMPTE Timecode In/Out: 3-pin XLR
- 12 VDC power supply input: 4-pin XLR
- Desk lamp (dimmable): XLR
- USB (storage media/hardware peripherals): Back of mainboard: 2 x USB 3.0, Side of console: 1 x USB 2.0
- Electrical:
- AC mains power to 12 VDC external PSU (included): 100-240 V nominal, 50/60 Hz
- Maximum current: 1.4 A
- 12 VDC output: 5 A, 60 W max.
- Accessories:
- Replacement 12 VDC external PSU: P/N 91613100
- Replacement LED desk lamp: P/N 91613090
- Dust cover for M2GO HD: TBA
- Flightcase for M2GO HD: TBA
- Elation M-Play: P/N 90737030
- Related Items:
- Elation Ether2DMX8™: P/N 90758130
- Elation M-DMX Interface Box / Elation M-PC 2U package: P/N 90737070
- Ordering Information: M2GO HD Console: P/N 90737080
