Shure UA834V In-Line Antenna Amplifier for Remote Mounting (174-216MHz)

The Shure UA834 provides more flexibility in wireless installations by increasing the allowable length of cable runs between a receiver and antenna. Antennas may be placed closer to the stage, or installed on ceilings and walls that maintain a better line of sight with the transmitter.

Shure UA834 Features:

• Two-position gain selector switch +6 and +12 dB
• Overload LED indication
• Low-noise signal amplifier compensates for insertion loss in coaxial cable
• Compatible with Shure Wireless Systems. Also may beused with Shure UA845 and UA844 Antenna Distribution Systems
• Integrated threaded adapter mounts easily tomicrophone stands or the supplied surface-mount bracket
• Shure quality, ruggedness, and reliability

Shure UA834 Specifications:

• Frequency Range: UA834V: 174–216 MHz
• Connector Type: BNC, Female
• Impedance: 50 Ohm
• Power Requirements: 10 to 15 V DC bias from coaxial connection, 0.60–0.72 W
• Signal Gain: +/- 2 dB, Switchable
• Absolute Maximum RF Input: +5 dBm
• Absolute Maximum RF Input: +5 dBm
• Input Third-Order Intercept Point (IIP3): >10 dBm
• Housing: Cast Aluminum, black painted finish
• Dimensions (HxWxD): 67 x 32 x 112 mm
  • Dimensions with Stand: 108 x 32 x 112 mm
• Net Weight:
  • Without Mounting Stand: 0.28 kg (9.8 oz.)
  • With Mounting Stand: 0.42 kg (14.8 oz.)
