Product Overview
This Canare HD-SDI cable is made from L-5CFW 75 Ohm flexible digital video coaxial cable and BCP-B51F 75 Ohm crimp plugs.
Canare HDSDI Features:
- Canare L-5CFW 75 Ohm Flexible Digital Video Coaxial Cable Features:
- Solid Copper Center Conductor
- Foam PE Dielectric
- Dual Copper Braid for Flexibility
- Precision Coax 100% Sweep Tested
- Canare BCP-B51F 75 Ohm Crimp Plug Features:
- True 75 ohm construction Crimp Pin & Sleeve
- High performance of 1.1 or less VSWR up to 3GHz
- Elongated Body for better finger grip
- Position mark on body allows the connector fit to be checked easily
- Superior cable pull strength
- Gold-plated center pins 'snap' into place
- Connector Body has been die-cast, achieving a lower price with higherperformance
- Easy Assembly using Canare Strip & Crimp Tools
Canare HDSDI Specifications:
- Canare L-5CFW 75 Ohm Flexible Digital Video Coaxial Cable Specifications:
- Nominal O.D.: 0.303" (7.7 mm)
- Conductor Material: Bare Copper
- #18 AWG
- Conductor O.D.: 0.041" (1.05 mm)
- Dielectric Insulation Type: Foam PE
- Dielectric Strength: 1000V AC/1 min
- Insulation O.D.: 0.193" (4.9 mm
- Shield Material Coverage (mm/ends/carriers):
- 0.12TA/7/24 (93% or more)
- 0.12TA/9/24 (96% or more)
- Canare BCP-B51F 75 Ohm Crimp Plug Specifications:
- Return Loss (0-3GHz): 26dB or greater
- Pull Strength: 245N for L-4.5CHD, 1694A
- Coupling Sleeve: Zinc Alloy Die Casting
- Center Pin: Gold Plating
- Weight: approx. 12.5g
Note
NOTE: The images above show the Canare HD-SDI cable in black. This version of the cable comes in red.
