SoundTube IW31-EZ-BK
3” Full Range Ceiling Speaker

OUR PART #  IW31-EZ-BK

Our Price: $105.00
List Price: $117.00
You save 10%! (Low Price Guarantee)
Usually ships in 7-14 business days.
Need it sooner? Call us!

The Soundtube IW31-EZ is a premium full-range 3-inch in-wall speaker for applications requiring 8 ohm or distributed audio solutions. The IW31-EZ incorporates a low profile grille with a total visible footprint of 5-inch square and an integrated backcan and driver design for an ultra compact installations in wall plates. The in-wall speaker includes a six-position tap switch with a transformer bypass position. Mounting hardware is included and features a fast and secure constant tension SpeedWing™ mounting system. All components in the IW31-EZ are completely weatherized for indoor and outdoor applications.

Soundtube IW31-EZ Features:

  • One 3-inch (76.1 mm) full-range high-extrusion, high-fidelity polypropylene driver with butyl rubber surround.
  • Weatherized components for indoor/outdoor applications.
  • Rapid installation, blind-mount fixed-wing mounting mechanism with constant tension design affixing to wall thicknesses ranging from 0.1 inch (2.5 mm) to 1.5 inch (38.1 mm).
  • Shallow 3.5-inch deep all steel backcan with integrated backcan, driver and baffle configuration.
  • Ultra-compact design with a total visible footprint of 5-inch square.
  • Corrosion-resistant, powder-coated aluminum grille with snap fit attachment
  • UL 1480 (UEAY) and 2043 approved.
  • High quality black or white paint finish.
  • Included accessories: Conduit connector, paint mask and wire nuts.
  • Optional accessories: Pre-construction bracket (AC-IW3-PCB),theft-resistant stainless steel grille (AC-IW3-TRG) and 10-inch poweredsubwoofer (SM1001p).

Soundtube IW31-EZ Specifications:

  • System Type: 3-inch full-range, in-wall (10-watttransformer for 25/70.7/100-volt or transformer bypass)
  • Impedance (nominal): 8 ohm
  • Max. Program Power: 40 W
  • Max. Continuous Power RMS: 20 W
  • Transducer - Full-Range Driver: 76.1 mm (3.0 in.)Polypropylene driver with butyl rubber surround
  • Low Frequency Voice Coil: 19.0 mm (0.75 in.)
  • Enclosure Material: ABS baffle, steel backcan
  • Grille: Corrosion-resistant, powder-coated aluminum
  • Inputs: Hardwire lead
  • Colors: White
  • Backcan Height: 88.9 mm (3.50 in.)
  • Visible Height: 127.0 mm (5.00 in.)
  • Visible Width: 127.0 mm (5.00 in.)
  • Weight: 1.4 kg (3 lbs.)
  • Shipping Weight: 1.8 kg (4 lbs.)
  • Packaging: One per box
  • Included Accessories: Conduit connector, paint mask and wire nuts
