Roland TB-03
Boutique Series Bass Line Synth


Our Price: $349.00
(Low Price Guarantee)
In Stock

Recommended Accessories

Roland's TB-03 takes the sound and controls of the famous TB-303 Bass Line Synth and packs them into a compact, battery-powered console. The TB-03 adds new features such as a four-digit LED display for easier programming, overdrive and delay effects, MIDI, fine tempo control, and more.

Roland TB-03 Features:

  • Realistic recreation of the iconic TB-303 Bass Line synth
  • Retains the sound, character, and user interface of the original TB-03
  • Hands-on control over expressive parameters, including cutoff, resonance, envelope mod, decay, and accent
  • New features not found on the original TB-303, including four-digit LED display, overdrive and delay effects, MIDI, fine tempo control, and additional functions for pattern creation
  • Programmable via classic Pitch, Time, and Step write modes
  • Continue playing a sequence even while switching between write and play modes
  • CV/Gate outputs for controlling vintage analog gear and modular synthesizers
  • Dedicated trigger input to drive the internal sequencer
  • Highly portable for mobile music making
  • High-quality construction with metal front panel
  • Battery-operated (4 x AA) or USB powered
  • 24 bit/96 kHz stereo IN/OUT USB audio interface
  • Control information can be sent and received via MIDIand USB
  • Built-in powered mini-speaker for instant enjoyment
  • Compatible with optional K-25m Keyboard Unit

Roland TB-03 Specifications:

  • User Memory
    • Patterns: 96 (4 groups (I, II, III, IV) x 3 sections (A, B, C) x 8 patterns)
    • Tracks: 7
  • Waveform
    • 2 (SAW, SQUARE)
  • Controls
    • VOLUME knob
    • TUNING knob
    • CUT OFF FREQ knob
    • RESONANCE knob
    • ENV MOD knob
    • DECAY knob
    • ACCENT knob
    • OVERDRIVE knob
    • DELAY TIME knob
    • WAVE FORM switch
    • TRACK PATT. GROUP selector
    • MODE selector
    • TEMPO button
    • VALUE knob
    • PATTERN CLEAR button
    • RUN/STOP button
    • PITCH MODE button
    • FUNCTION button
    • Keyboard buttons (C, C#, D, D#, E, F, F#, G, G#, A, A#, B, C)
    • TIME MODE button
    • TRANSPOSE UP/DOWN buttons
    • ACCENT button
    • SLIDE button
    • BACK button
    • TAP button
  • Effects
    • OVERDRIVE (Overdrive/Distortion)
    • DELAY (Tape Echo/Digital Delay/Reverb)
  •  Indicators
    • 7 segments, 4 characters (LED)
  • Connectors
    • TRIGGER IN jack: Mono miniature phone type
    • CV OUTPUT jack: Mono miniature phone type
    • GATE OUTPUT jack: Mono miniature phone type
    • PHONES jack: Stereo miniature phone type
    • OUTPUT jack: Stereo miniature phone type
    • MIX IN jack: Stereo miniature phone type
    • MIDI (IN, OUT) connectors
    • USB port: Micro-B type (Audio, MIDI)
  • PowerSupply
    • Rechargeable Ni-MH battery (AA, HR6) x 4
    • Alkaline battery (AA, LR6) x 4
    • USB bus power
  • CurrentDraw
    • 500 mA (USB bus power)

  • Expectedbattery life under continuous use

    • echargeable Ni-MH battery: Approx. 5 hours (varies depending on the specifications of the batteries, capacity of the batteries, and the conditions of use)

  • Dimensions:12-1/8"W x 5-1/8" D x 2-1/16 H"
  • Weight(including batteries, excluding Boutique Dock): 2lbs 2 oz
  • Accessories
    • Boutique Dock: DK-01 (Silver)
    • Owner's Manual
    • DK-01 Owner's Manual
    • Alkaline battery (AA, LR6) x 4
