Zeiss 1457-856
Black Distagon T* 2.8/15 ZM Lens with Lens Shade

OUR PART #  1457-856

Our Price: $4,600.00
Usually ships in 7-14 business days.
Need it sooner? Call us!

ZEISS lenses are compatible with most industrial cameras. The F-Mount and the M42 Mount are popular standard for high-resolution industrial cameras with large sensor sizes up to 24 x 36 mm and for line scan cameras with sensors up to 43 mm. ZEISS lenses are widely used in machine vision, automation, quality inspection, optical metrology as well as in research and development e.g. with High Speed cameras. Thanks to the large image format, our objective lenses are ideal for the constantly increasing use of high-resolution image sensors with bigger sensor formats. Due to the precise manual adjustment of the helical focusing mount you will gain much better results than with comparable lenses. The Distagon T* 2.8/15 ZM inlcudes a lens shade.

Zeiss Distagon T* 2.8/15 ZM Features:

  • Fast f/2.8 aperture
  • Precise manual focusing
  • Robust full-metal construction
  • Identical color reproduction of all models
  • For industrial cameras with F-Mount up to sensor sizes of 24x36 mm or 43mm line sensors
  • 110° angular field

Zeiss Distagon T* 2.8/15 ZM Specifications:

  • Focal length: 15 mm
  • Aperture range: f/2.8 – f/22 (1/ 2 stop intervals)
  • Number of elements / groups: 15/12
  • Min. working distance (object to sensor): 250 mm (0.83 ft.) – 8
  • Min. free working distance: 90 mm (0.3 ft.) – 8
  • Angular field (diag. / horiz. / vert.): 110 / 100 / 76°
  • Max. diameter of image field: 43 mm (1.7")
  • Flange focal length F-mount: 46.5 mm (1.8"); M42 Mount: 45,5 mm
  • Coverage at close range: 340 x 221 mm (13.4 x 8.7"), line 387 mm (15”)
  • Image ratio at close range: 1:9
  • Filter-thread: M 95 x 1.0
  • Weight: 730 g (1.61 lbs.)
  • Camera mount: F bayonet, M42, EF
Add to Cart

We're sorry, only of this item available

Call a Sales Pro at 800-356-5844 for more information
