Panasonic TH-49AF1U
49" LCD Professional Signage Display with Android-based OpenPort PLATFORM


Our Price: $1,804.37
List Price: $1,989.00
You save 9%!
Usually ships in 7-14 business days.
Need it sooner? Call us!

Panasonic's TH-49AF1U, the 49" model in their AF1 display series, is simple, expandable, reliable, and features an Android™-based OpenPort PLATFORM™ powered by a high-performance SoC (System on a Chip) with a 1 GHz quad-core CPU, 1 GB of memory, and 8 GB* internal storage. Together with verified apps created by global alliance partners for custom signage and other roles in business, these adaptive displays can deliver your message with maximum impact now and for the future.

*Total capacity of storage including OS.

 A Dependable, Fully Certified Platform
The OpenPort PLATFORM™ based on Android™, is fully certified by Google. It assures stable, secure, and reliable operation.

Mutual Check with App Alliance Partners
Applications running on OpenPort PLATFORM™ are fully vetted by alliance partners and Panasonic for stable, secure functionality.

Simple Setup and Easy Operation No Need for External Devices and Cables
With the onboard media player function, external devices like set-top boxes, PCs, and associated cabling aren't needed for digital signage usage. Wireless functionality provides simple, stress-free installation, while saving you time and money.

Simple App Installation
Easily access and install Applications via Panasonic App Server*, which streamlines the settings before use. App installation is also provided via USB drive or microSD card.

*Total capacity of storage including OS.

Flexible and Expandable Digital Signage

Panasonic API Expands Application Functions
Panasonic's clear and intuitive API (Application Programming Interface) allows the expansion of application functions, enabling the display to be controlled remotely with no need for RS232C or other complicated applications.

Supports External Memory Devices
USB drives and microSD cards can also be implemented to expand the 8 GB internal memory storage capacity.

Supports Connection of Peripheral Devices
Peripheral devices like mouse, keyboard, or USB camera can be connected to AF1 Series displays, giving further expansion of their functionality.

Cloning Function Saves Time When Setting Up Multiple Devices
Using a USB memory stick, you can easily copy settings data from a master display to other displays, which reduces labor, and ensures multiple device setup consistency.

Note: Function supported on displays of the same size and series only.

High Brightness and Off-Axis Visibility Design

Bright and Stylish IPS Display
The AF1 Series features efficient edge-LED IPS panel technology, providing brightness of 500 cd/m², and assuring uncommonly good off-axis visibility that maintains color accuracy even in bright ambient light situations. Additionally, the displays feature a slim 6.3mm (0.25") bezel that increases perceived image size.

Dependability You Can Count On

Fanless Design
The durable fanless design prevents issues caused by the intake of dusty air, thus allowing the displays to be safely installed and operated in high-traffic environments.

Failover and Failback Safeguards for Mission Critical Situations
The AF1 Series comes equipped with HDMI, DVI-D, and USB terminals. If an interruption occurs to the main video and audio signals, the system immediately switches to alternative signals. When primary input signals are restored, the original image is automatically reinstated. These safeguards are essential when the displays are used in control rooms, surveillance centers, and any other mission-critical applications.

Multi Monitoring & Control Software
This free software available from Panasonic offers monitoring and control of up to 2,048 devices via a LAN network, and all from a single PC if needed. For monitoring, the status of each device can be listed in groups, plus detailed information on individual displays can also be separately shown. Control functions include power ON/OFF, input switching, command inputs, and scheduling.

Multi Monitoring & Control Software

Optional Early Warning Software (ET-SWA100 Series - sold separately)
Optional ET-SWA100 Series* Early Warning Software provides monitoring for the displays and projectors connected to an intranet, and informs you when an abnormality is detected or there are symptoms of trouble. A monitoring server can be controlled remotely via tablet or PC, when this software installed.

*Part number suffix may differ depending on the license type.

Panasonic TH-49AF1U Includes:

  • TH-49AF1U unit
  • 79" (2.0m) AC Cord
  • Remote Control
  • (2) AAA Batteries
  • (3) Clampers
  • CD-ROM User Manual
  • Operating Instructions Booklet

Panasonic TH-49AF1U Specifications:

  • Screen Size: 49"
  • Brightness: 500cd/m²
  • Bezel Width: 6.3mm
  • Mounting Orientation: Landscape / Portrait
  • Onboard Speakers: Yes
  • Physical:
    • Dimensions:
      • 43.1" W x 24.6" H x 2.8" D (1093 x 623 x 72mm)
      • (excluding handle) 43.1" W x 24.6" H x 2.3" D  (1093 x 623 x 57mm)
    • Weight: Approx: 42.6 lbs.
