TOA A-5006
4 in Mixer/Amp, Network DSP, 60W @ 70V

OUR PART #:  A5006

The TOA A-5006 is a half-rack 1-unit size 60 W desktop mixer power amplifier.
Learn More
Our Price: $484.76
List Price: $599.89
You save 19%!
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

TOA A-5006
Qty:
In Stock

Similar Products

The TOA A-5006 is a half-rack 1-unit size 60 W desktop mixer power amplifier. Inputs 1 and 2 can be set for either MIC or LINE sound sources, and its output is compatible with both high-impedance (100 V and 70 V lines) and low-impedance (4 O) speaker connections.Functions can be set with a PC using the dedicated setting software. The A-5006 is ideal for use asa power amplifier in small commercial facilities and conference rooms.With the use of an optional rack mounting bracket, it can be mounted in an EIA Standard equipmentrack (1 unit size).

TOA A-5006 Specifications:

  • Power Source: 100-240 V AC, 50/60 Hz
  • Rated Output: 60 W
  • Power/Current Consumption: 106 W (rated output), 20 W (based on cULus standards) Max. 2 A
  • Frequency Response: 50 Hz - 20 kHz (1/8 rated output)
  • Distortion: 1 % or less (1 kHz, rated output)
  • Input:
    • INPUT 1, 2: MIC -60 dB (*1)
    • LINE -20 dB(*1) MIC/LINE selectable
    • 2.2 kOhm, electronically-balanced, removable terminal block (5 pins)
    • INPUT 3, 4: LINE -20 dB(*1), 10 kO, unbalanced, RCA pin jack
  • Output:
    • SPEAKER: 4 Ohm, 70 V (83 Ohm), 100 V (170 Ohm), removable terminal block (5 pins)
  • Signal to Noise Ratio:
    • MIC 1, 2: 50 dB or more
    • LINE 1 - 4: 70 dB or more
  • Function:
    • Parametric equalizer: 5 points settable on each input and output
    • 20 Hz - 20 kHz +/- 15 dB
    • Q: 0.267 - 69.249
    • Compressor: ON/OFF settable on Inputs 1 and 2 (OFF by default)
    • Threshold, Ratio, Attack time, Release time, and Gain are settable  independently on each input.
  • Control: Mute control, Remote master volume control, Power ON/OFF switch, Ground lift
  • LED Indicator: Power indicator, Signal indicator, Peak indicator, Protect indicator
  • Network I/F: 100BASE-TX
  • Operating Temperature: 32°F to 104°F (0° to +40°C)
  • Operating Humidity: 35 % to 80 % RH (no condensation)
  • Finish:
    • Panel: PS resin, black
    • Case: Surface-treated steel plate, black, paint
  • Dimensions (WxHxD): 8.27" x 2.07" x 14.76" (210 x 52.5 x 375 mm)
  • Weight: 7.94 lb (3.6 kg)
Half-Width Rack Mounting Bracket
TOA MB15B-BK Half-Width Rack Mounting Bracket
Features: "Half Width" Rack Mounting Bracket. Includes half width blank panel to fill the gap left when rack mounting half width products.
