TV One 2211114-02
HD-One DX500 Kit

OUR PART #:  2211114-02

tvONE's HD-One DX 500 is an audio extension kit.
Learn More
Our Price: $700.00
Write the first review.
TV One 2211114-02
Usually ships in 7-14 business days.
Need it sooner? Call us!

Related Products

tvONE's HD-One DX 500 is an audio extension kit. Magenta engineered an HDMI video and audio extension kit that can send 1920x1200 resolution HDCP-protected video and embedded audio to a distance of 500 feet (152 meters), all on a single Cat6. TX or RX may be ordered individually. While the HD-One Series is already known for its picture quality, ease-of-use and reliability, the HD-One DX500 goes a step further, boasting improved heat dissipation, lower power consumption and significantly better resistance to emissions.

tvONE DX500 Kit Includes:

  • One transmitter
  • One receiver
  • Two universal power supplies

tvONE DX500 Kit Features:

  • HDMI 1.4 and HDCP compliant
  • Uncompressed HD video to 1920x1200 @ 60Hz at 500ft (152m)
  • Single UTP cable transfers video, audio and HDCP signals
  • Audio transmission supports Dolby TrueHD, DTS-HD Master Audio

tvONE DX500 Kit Specifications:

  • Supported Video: HDMI/DVI Video Modes
  • HDMI 1.4, HDCP Compliant including standard formats @ 60Hz:640x480, 800x600, 1024x768, 1152x864,1280x768, 1280x960,1280x1024, 1360x760, 1366x768, 1600x1200,1680x1050, 1920x1080, 1920x1200 & HDTV: 480p,720p,1080i, & 1080p.
  • Video In: HDMI Type A (Transmitter)
  • Video Out: HDMI Type A (Receiver)
  • Audio In/Out: Embedded with video signal
  • UTP In/Out: RJ45 Connector
  • Required UTP: CAT5e, CAT6, CAT6a, CAT6e, CAT7 UTP/STP/FTP (CAT6 or better is recommended)
  • Bandwidth: 3.4 Gbps
  • RS-232 Baud Rate (LX): To 115200bps; Full Duplex
  • RS-232 Connector (LX): DB9 Female / DB9 Female
  • IR Carrier (LX): 36.7, 38.0, or 56.8 kHz modulated emitter output; Bi-directional
  • Power: +5 VDC @ 2.6A max each unit
  • Consumption: 1200 mA max Consumption: 600mA(max) / 1200mA(max)
  • Dimensions (DX): 3.2” x 1.9” x 1.0” (82 mm x 48.6 mm x 24.8 mm)
  • Dimensions (LX): 5.1” x 3.5” x 1.2” (130mm x 88 mm x 30mm)
  • Weight: DX: 0.3 lb (0.14 kg) each LX: 0.6 lb (0.28 kg) each
  • Humidity Tolerance: Up to 95% non-condensing
  • Operating Temperature: 0° to 55° C
  • Storage Temperature: -20° to 85° C
  • Warranty: 3 years
